Installation

3.10 Checking Network Cabling

NOTICE
After installing the BACnet/IP interface, be aware of the
following parameter settings:
3 3
•
Parameter 8-01 Control Site: [2] Control word only
or [0] Digital and control word
•
Parameter 8-02 Control Word Source: [3] Option
A.
•
Parameter 8-03 Control Timeout Time.
•
Parameter 8-70 BACnet Device Instance.
•
Parameter 12-71 BACnet Datalink.
If BACnet/IP is used the following parameters must be
set correctly:
•
Parameter 12-00 IP Address Assignment.
•
Parameter 12-01 IP Address (if parameter 12-00 IP
Address Assignment is set to [0] MANUAL).
•
Parameter 12-02 Subnet Mask (if
parameter 12-00 IP Address Assignment is set to
[0] MANUAL).
