9. J1 Male Header

The J1 male header provides power pins and additional I/Os from either the MachXO3-9400 Development Board or the
ECP5 Versa Development Board's expansion connector which are not connected to the ASC Breakout Board
connectors.

Table 9.1. J1 Male Header Connections for use with MachXO3-9400 or ECP5 Versa Develpment Board

J1 Pin Silkscreen
Number Name
1 +3.3 V
2 +2.5 V
3 N.C.
4 EXPCON_OSC
5 EXPCON_CLKIN
6 EXPCON_CLKOUT
7 HPE_RESOUT#
8 EXPCON_IO0
9 EXPCON_IO2
10 EXPCON_IO14
11 EXPCON_IO17
12 CARDSEL#
13 GND
14 GND
15 GND
16 GND
17 GND
18 GND
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
Notes:
When using the MachXO3-9400 Development Board the J1 pin 4 signal EXPCON_OSC comes from either the on-board oscillator
Y2 or from an off-board source using J10.
When using the ECP5 Versa Development Board the J1 pin 4 signal EXPCON_OSC comes from the on-board Lattice
ispClock5406D device.
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0
MachXO3-9400
Ball Port
––
––
––
1
(Note)
A10 PT23B
A21 PT44A
G9 PT21D
F8 PT11C
F9 PT21C
C6 PT14C
D8 PT15B
C13 PT29C
––
––
––
––
––
––
––
––
––
––
––
––
Evaluation Board User Guide
ECP5-45
Ball Port
––
––
––
2
(Note)
A10 PT36A
E11 PT42B
A8 PT18B
A12 PT49A
B13 PT51A
A9 PT33A
B15 PT69A
A7 PT18A
––
––
––
––
––
––
––
––
––
––
––
––
ASC Bridge Board
FPGA Board
Signal Name
––
––
––
EXPCON_OSC
EXPCON_CLKIN
EXPCON_CLKOUT
HPE_RESOUT#
EXPCON_IO0
EXPCON_IO2
EXPCON_IO12
EXPCON_IO16
CARDSEL#
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
11
