Pneumatic Cylinder Adjustment

(Prior to January 19, 2009)
NOTE: If chair rises by itself, sinks with an occupant or does
not raise or lower when seat height lever is lifted, the cylinder
adjustment screw may not be in the correct adjustment.

Adjustable Seat Depth

1.
Slide seat fully forward while holding the seat slide lever.
2.
Locate the white quick release tab located on the left
hand side of the chair (as you sit in it) between the plates.
3.
Lift the quick release tab while pulling the seat slide lever
and sliding the seat forward.
FRONT
1
REAR
2
FRONT
3
QUICK RELEASE TAB
SEAT SLIDE LEVER
REAR
