CAME F1000 Installation Manual
Operator for swing gates
Hide thumbs
Also See for F1000:
- Installation manual (49 pages) ,
- Standard installation (16 pages) ,
- Manaul (16 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CAME F1000
Summary of Contents for CAME F1000
- Page 1 Operator FA01175-EN for swing gates F1000-F1100 INSTALLATION MANUAL EN English...
- Page 2 WARNING! important safety instructions for people: READ CAREFULLY! • REMISE PREVENT POTENTIALLY HAZARDOUS SITUATIONS EAD THE INSTRUCTIONS IF THE POWER • E MPLOY THIS PRODUCT ONLY FOR THE USE FOR WHICH IT WAS EXPRESSLY MADE SUPPLY CABLE IS DAMAGED IT MUST BE REPLACED BY THE MANUFACTURER OR AUTHORIZED .A.
-
Page 3: Legend Of Symbols
Description Gearmotor This product is engineered and manufactured by CAME S.p.A. and complies with current safety regulations. The gearmotor is composed of two, cast aluminium half shells inside of which rest the gearmotor and endstops – with electro blo- cking – and an endless screw, epicycloidal gear reduction system. -
Page 4: Description Of Parts
Description of parts 1) Base plate 2) Gearmotor assembly 3) Motor cover 4) Articulated transmission arm Optional accessory : F1001 Straight telescopic arm (for single gate wings that are 0,5 to 2 m max long). Overall dimensions Installation Installation must be carried out by expert qualified personnel and in full compliance with current regulations. Preliminary checks Before installing, do the following: •... -
Page 5: Standard Installation
Tools and materials Make sure you have all the tools and materials you will need for the installation at hand to work in total safety and compliance with the current standards and regulations. The following figure illustrates the minimum equipment needed by the installer. Cable list and minimum thickness Connection Type of cable Cable length 1 <... - Page 6 Mounting - Secure the base plate to the pillar using ø8 screws and ø14 moulded inserts making sure the minimum distance of 150mm from the ground is met. - Secure the A bracket (using ø8 screws or by welding) to the gate leaf making sure the 450mm and 19mm distances measurements and are met.
- Page 7 - Insert the straight semi-arm into the motor shaft. Apply the fl ared washer, the M6x20 screw and lock the semi-arm using the two grub screws. Join and secure the two arms using the washer and M8x16 screw. Release the motor (see p. 7) and secure the curved semi-arm to the “A”...
- Page 8 Adjusting the closing and opening-speed brake microswitches During opening: release and move the door to the open position desired. Turn the upper cam until the microswitch is activated and screw the microswitch is activated and screw the screw in the related cam. During closure (F 1000 only): release the door and move it to the desired closing position.
- Page 9 Connecting to the ZA3N/ZF1N/ZM3E control panel Control panel terminal board Motor terminals Ground If only using one motor, such as with one-leaf gates, connect it to W X Y (M2) regardless of which side it is installed on. INSTALLING AND CONNECTIONS FOR OUTWARD-OPENINGS Below are the only procedures that vary compared to standard installations: Securing the brackets N.B.
-
Page 10: Maintenance
Electrical connections For electrical connection operations, use the chamber and the junction boxes. For further information regarding functions and adjustment, refer to the technical documentation for the control panel. Control panel terminal board Motor terminals Ground If only using one motor, such as with one-leaf gates, connect it to W X Y (M2) regardless of which side it is installed on. Maintenance Periodic maintenance Before doing any maintenance, cut off the power supply, to prevent any hazardous situations caused by accidentally activating the operator. -
Page 11: Troubleshooting
Extraordinary maintenance The following table is for logging any extraordinary maintenance jobs, repairs and improvements performed by specialized contractors. Any extraordinary maintenance jobs must be done only by specialized technicians. Extraordinary maintenance log Installer's stamp Name of operator Job performed on (date) Technician's signature Requester's signature Job performed... -
Page 12: Demolition And Disposal
CAME S.p.A. employs a UNI EN ISO 14001 certified and compliant environmental protection system at its plants, to ensure that environmental safeguarding. We ask you to keep protecting the environment, as CAME deems it to be one of the fundamental points of its market operations strategies, by simply following these brief guidelines when disposing: DISPOSING THE PACKING MATERIALS The packing components (cardboard, plastic, etc.) are solid urban waste and may be disposed of without any particular difficulty, by... - Page 13 CONTROL PANEL FA00679-EN FOR 120 V OR 230 V GEARMOTORS ZF1N110 / ZF1N EN English INSTALLATION MANUAL...
-
Page 14: Intended Use
All connections and links are rapid-fuse protected. Intended use The ZF1N110 / ZF1N control panel is designed to control CAME gearmotors for swing gates in private homes and apartment buildings. Any installation and/or use other than that specifi ed in this manual is forbidden. -
Page 15: Preliminary Checks
Description of parts ① Transformer ② Line fuse ③ Power supply terminals ④ Transformer terminal boards ⑤ Control-board fuse ⑥ Terminals for control and safety devices ⑦ Alert LED ⑧ Antenna terminal ⑨ DIP-SWITCH ⑩ AF card connector ⑪ Automatic closing trimmer ⑫... -
Page 16: Tools And Materials
Tools and materials Make sure you have all the tools and materials you will need for installing in total safety and in compliance with applicable regulations. The fi gure shows some of the equipment installers will need. Cable types and minimum thicknesses cable length Connection <... -
Page 17: Installation
INSTALLATION Fastening the control panel Fasten the control panel in a protected area using suitable screws and dowels . Only use 6 x 70 mm cylinder-head screws. Drill through the pre-drilled holes (18 and 20 mm) under the control panel's base . Be careful not to damage the control board. - Page 18 Connecting the gearmotors Gearmotor (M1) 120 V AC* or 230 V AC, Gearmotor (M2) 120 V AC* or 230 V AC, delayed when opening. delayed when closing. FERNI FERNI FAST FAST KRONO KRONO * 120 V AC version if available U V W X Y E Motor's torque limiter To vary the motor torque, move the faston as shown to one of the four positions: 1 min ÷...
- Page 19 Command and control devices TS 5 C1 7 2 1 11 10 ES ES STOP button (NC contact). For stopping the gate while excluding automatic closing. To resume movement press the control button or use another control device. If unused, short-circuit the contact. OPEN-CLOSE-INVERT function (step-step) from control device (NO contact).
- Page 20 Safety devices Photocells Input for safety devices such as photocells. Reopening during closing. When the gate is closing, opening the contact triggers the inversion of movement until the gate is fully open again; If the photocells are left unused, short-circuit contact 2-C1. TS 5 C1 7 2 1 11 10 ES ES TS 5 C1 7 2 1 11 10 ES ES - NO C...
-
Page 21: Functions And Settings
FUNCTIONS AND SETTINGS Functions DIP-SWITCH Description of functions AUTOMATIC CLOSING Automatic closing active (1 OFF - Deactivated) OPEN-STOP-CLOSE-STOP OPEN-STOP-CLOSE-STOP (sequential) function from control device (NO contact) and from radio transmitter fitted with AF card. OPEN-CLOSE-INVERT OPEN-CLOSE-INVERT (step-step) function from control device (NO contact) and from radio transmitter fitted with AF card. -
Page 22: Preliminary Operations
MANAGING USERS BY RADIO CONTROL Preliminary operations Connect the RG58 cable antenna cable to the corresponding terminals . Fit the AF card into the control board connector . Before fi tting the AF card, you MUST CUT OFF THE MAIN POWER SUPPLY and, remove any emergency bat- teries. -
Page 23: Deleting A Single User
Deleting a single user Set DIP-switch 4 to ON. Keep pressed the PROG button on the control board. The programming LED fl ashes. Within fi ve seconds, press the button on the transmitter of the user you wish to delete. The LED will fl ash quickly for one second to signal that the user has been deleted, and then it will switch off . -
Page 24: Final Operations
These must therefore be disposed of by authorized, certifi ed professional services. DISPOSE OF RESPONSIBLY! REFERENCE REGULATIONS CAME SpA declares that this product complies with the current directives at the time it is manufactured. CAME S.p.A. Via Martiri Della Libertà, 15 31030 Dosson di Casier - Treviso - Italy tel.
