The meaning of signals provided by the green LED [B], when the red LED [A] is off, are
described in the following table.
Light signals
The green LED is off.
The red LED is off.
The green LED blinks fast.
The red LED is off.
The green LED repeats the sequence: a
blink and a pause.
The red LED is off.
The green LED repeats the sequence:
two blinks and a pause.
The red LED is off.
The green LED repeats the sequence:
three blinks and a pause.
The red LED is off.
The meaning of the green [B] and red [A] LED signals cannot be modified.
7.2

Acoustic signals

The DJS Transmitting Unit has an acoustic signal device that activates when:
- The battery is nearly flat,
- the Transmitting Unit has been on for eight hours,
- The Transmitting Unit does not work correctly,
- during the Radio Remote Control start-up, the STOP pushbutton is pressed or damaged,
- during the Radio Remote Control start-up, the SAFETY command is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands D2-D20 is activated
(see Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands A1-A8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands H1-H8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, one of the commands L1-L8 is activated (see
Technical Data Sheet),
- during the Radio Remote Control start-up, the battery is flat.
The acoustic signal device activates whenever the red LED [A] illuminates. The meaning of
red LED [A] signals and of the acoustic signal device, and the possible actions to adopt are
described in chapter 11.
The meaning of the acoustic signals cannot be modified.
LIUDJS001_eng-01
Light and acoustic warning signals
Meaning
The Transmitting Unit is off.
The Transmitting and Receiving Unit do not
communicate.
The Radio Remote Control is started and the Units
communicate via radio link in the 863-870MHz
frequency band.
The Radio Remote Control is started and the Units
communicate via radio link in the 915-928MHz
frequency band.
The Radio Remote Control is started and the Units
communicate via cable control.
AUTEC - Dynamic+ series
