REVO-TC / TU-RS485-PNT0TCMxx Communication Manual
1.1.1.4 Connection with Revo TC
TU-RS485-
PNT0TCMxx
9
Master RS485
Tx/Rx+
3
Master RS485
Tx/Rx-
1.1.1.5 Revo TC Addressing
The Revo TC addressing on a Revo TC system is like follow
Addr 1
The first Revo TC is address 1 the second address 2 and so on
12
6
11
5
4
10
9
3
8
2
7
1
Addr 2
Addr 3
4
REVO TC
TU Module
2
Tx/Rx+
1
Tx/Rx-
Addr n
