REVO-TC / TU-RS485-PNT0TCMxx Communication Manual
1.1.1.3 Digital Output
The digital output, is an open collector output, used to indicate the communication error status.
This option is available from firm Ver 2.24.000 and configuration Ver 1.2
Voltage supply
Max current
Output
Status
Open
RS485 Communication ok
Closed
at least one instrument is in communication error
12
6
5
11
10
4
3
9
8
2
1
7
:24Vdc
:150mAM
-
24Vdc
+
3
