Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION ----------------------------------------------------------------------------------------------- 3 2. UNPACKING ---------------------------------------------------------------------------------------------------- 3 3. SAFETY ----------------------------------------------------------------------------------- 3 3.1 .Specified conditions of use ----------------------------------------------------------------------------------- 3 3.2. General safety instructions ----------------------------------------------------------------------------------------------- 5 3.3. Safety devices 4. ASSEMBLY --------------------------------------------------------------------------------------------------- 5 5. OPERATION ------------------------------------------------------------------------------------ 8 5.1. Setting the depth of cut --------------------------------------------------------------------------------- 8 5.2. -
Page 3: Specification
1. SPECIFICAION Motor 230v/50HZ, 2.2 KW S6 20% Max cutting height at 45 0/90° 50/90 Table dimensions 550x800 Table extension (optional) 550x800 Working height Saw blade diameter / bore 315 x 3.0 x 30 Blade speed ( 50 Hz) 2800 Weight (N.W. - Page 4 Provide proper lighting. Prevent adverse body positions, Ensure firm footing and keep you balance at all times. Use suitable work-piece supports when cutting long stock. Do not operate tool near inflammable liquids or gases. 4. The saw shall only be started and operated by persons familiar with circular saws, and who are at any time aware of the dangers associated with the operation of such tool.
-
Page 5: Safety Devices
Hazard generated by insufficient personal protection gear! Wear hearing protection. Wear safety glasses. Wear dust mask. Wear suitable work clothes. When working outdoors wearing of non-slip shoes is recommended. 3.3 Safety devices (Pic.1 and Pic.2) Riving knife (a) The riving knife prevents the work-piece from being caught by the rising teeth of the saw blade and being thrown against the operator. - Page 6 Stand assembly (Pic. 3) The four folded legs have been folded before shipment. To assemble the stand: unfold the four legs and tighten the wing nuts securely. insert the short crossbeams and tighten the Knurled nut. NOTE: The carriage bolts (a) must be positioned in the groove to fasten through wing nut. Install dust collect (Pic.
- Page 7 Saw blade installation (Pict. 6, 7 and 8) 1. Raise motor fully. 2. Take the blade (c), the centering flange (d), the tightening flange (b), the left side nut (a) and the adjusting washer (e). In order, insert: adjusting washer (e) centering flange (d) blade (c) tightening flange (b)
-
Page 8: Operation
Install rip fence w / guide extrusion (Pic. 9) 1 .For use as rip fence the long fence extrusion must be installed. It is mounted on the guide extrusion at the front of the table. 2. Slide the head of the carriage bolts into the guide extrusion. 3. -
Page 9: Sawing With The Mitre Fence
1 .The rip fence is placed from top onto the guide extrusion at the front of the saw and locked with the lock lever. 2. Set the cutting height of the saw blade. The blade guard must rest with its front edge on the workpiece. 3. -
Page 10: Wiring Diagram
3. Dismount add-on parts (fence, sliding carriage, table extension) 4. If possible use original carton for shipping. 9. WIRING DIAGRAM PLUG (a), NVR-SWITCH (b), CABLE (c), MOTOR 10. AVAILABLE ACCESSORIES a. Wheel set (Standard) (Pic. 11) Universal Wheel Set for easy moving. Wheel A'ssy , ……………………………………………………..2 Handles…………………………………………………………….2 Hexagonal bolt M6x16……………………………………………4... - Page 11 Rear extension use (Pic.13-a): 1. Install table extension (200) downward, and secure the four "n" shape slot into the gap of the four hexagon head w/flange screws on the rear side of main table. 2. Fit M6x16 carriage bolt (203) into the hole on the cross-beam from the outside. 3, Fit the wing nut M6 (204) on the bolt.
- Page 12 Installation (Pic.15): 1. Place angle plate of mitre fence (4) on the sliding carriage table (3), screw the M6 knurled screw (5) into the tapered hole of the sliding table. 2. Use 4 M6x16 pan head screws (9) mount two rail support (7 on two legs of machine.
-
Page 13: Parts List
11. PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Hexagonal bolt M6X16 Washer 6mm Hexagonal nut self-locking M5 Hexagonal nut M6 Blade cover (right) Handwheel / blade rise & fall Blade cover (left) Washer 10mm Sunk head tapping screw ST3.5X Thread rod support Sunk head screw M5X30 Ring retaining... -
Page 14: Parts Diagram
12. PARTS DIAGRAM...
