Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
14" Abrasive Cut Off Saw
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
01308 / 01315
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
Ref: 061216
24
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIP 01315
Summary of Contents for SIP 01315
- Page 1 This will allow the recycling of raw materials and help protect the environment. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 01308 / 01315 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
-
Page 2: Declaration Of Conformity
As the manufacturer's authorised representative within the EC declare that the 14” Abrasive Cut Off Saw - SIP Part No. 01308 14” Abrasive Cut Off Saw (110v) - SIP part No. 01315 Conforms to the requirements of the following directive(s), as indicated. 2006/42/EC... -
Page 3: Table Of Contents
Safety Symbols Used Throughout This Manual Safety Instructions Electrical Connection Guarantee Contents and Accessories Technical Specification Getting to Know Your Abrasive Cut Off Saw Operating Instructions Maintenance Wiring Diagram Exploded Drawing Parts List - 01308 Parts List - 01315 Declaration of Conformity... -
Page 4: Safety Symbols Used Throughout This Manual
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL NOTES Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Warning: Risk of electrical injury or damage! Note: Supplementary information. SAFETY INSTRUCTIONS IMPORTANT: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the abra- sive cut off saw. - Page 5 PARTS LIST - 01315….cont SAFETY INSTRUCTIONS….cont quate space surrounding the work area. Do not use in environments with a potentially Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. explosive atmosphere. KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors...
- Page 6 USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or Washer WK08-00003 Spring Washer WK08-00033 SIP directly for recommended accessories. Follow the instructions that accompany Locking Handle WK08-00004 Roll Pin WK08-00034 the accessories. The use of improper accessories may cause hazards and will invali-...
- Page 7 Use of improper accessories may cause damage to the abrasive cut off saw and surrounding area as well as increasing the risk of injury. Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. Do not modify the abrasive cut off saw to do tasks other than those intended.
- Page 8 SAFETY INSTRUCTIONS….cont PARTS LIST - 01308 Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. When using the saw always ensure the operator as well as those in Lock Bolt WK08-00001 Clamp Nut WK08-00031 the area wear ear protection.
-
Page 9: Electrical Connection
/ repaired by a suitably qualified person. If it is necessary to replace the plug a heavy duty impact resistant plug would be prefera- ble. The abrasive cut off saw (01315) is supplied with no plug fitted. The wires for the plug are coloured in the following way:... -
Page 10: Guarantee
Guarantee: Remove the rear motor cover by loosening and removing the 2 screws (M) This SIP abrasive cut off saw is covered by a 12 month parts and labour warranty cov- (Photo 006). ering failure due to manufacturers defects. This does not cover failure due to misuse or Pull up the brush spring (N) and pull the old brush out (O) (Photo 007). -
Page 11: Technical Specification
Replace or repair damaged parts. Use genuine parts only. Non-authorised parts may be dangerous and will invalidate the warranty. SIP Part No. 01308 01315 DO NOT use the abrasive cut off saw if it is, or has parts that are worn, dam- aged or missing;... -
Page 12: Getting To Know Your Abrasive Cut Off Saw
GETTING TO KNOW YOUR ABRASIVE CUT OFF SAW OPERATING INSTRUCTIONS TO RAISE THE HEAD To raise the head prior to cutting, push the head down and pull out the head lock pin (Photo 001) and the head will raise. Head lock pin MAKING A CUT Danger / Caution: The abrasive disc bolt must be tight at all times, check before each use and at regular intervals during operation.
