Minimum space with lever arm
If supplied with a lever arm, the Unilift CC pump can
be installed in a narrow pit.
The minimum dimensions for a narrow pit are 300 x
350 mm.
Fig. 3
Unilift CC with lever arm

2.2 Mechanical installation

2.2.1 Foundation
Place the pump on a plate or on bricks so that the
inlet strainer is free of silt, mud or similar materials.
Fig. 4
Pump mounted on a plate
2.2.2 Lifting the product
Lift the pump by the lifting handle. Never lift the
pump by the power cable. Tie a rope to the lifting
handle
instead.
Fig. 5
Lifting the pump
4
2.2.3 Positioning the product
The pump can be placed in three positions: vertical,
tilted or horizontal. The outlet port must always be
the highest point of the pump. During operation, the
inlet strainer must be covered by the pumped liquid
to ensure efficient cooling.
Fig. 6
Pump positions
2.2.4 Connecting the outlet pipe
The outlet pipe can be connected to the pump outlet
port on the top or the side by means of an adapter.
Use the 90 ° adaptor for the side outlet port.
Fig. 7
Connecting the outlet pipe
The adapter enables connection of a pipe or hose
matching 3/4", 1" and 1 1/4" external pipe thread (G).
Cut off the adapter so that it matches the outlet pipe
diameter. If a system gasket is used between the
outlet pipe and the adapter, the cut-off adapter must
have an even and smooth surface.
The approval according to DIN EN 12056-4
stipulates that the outlet pipe from the fixed
installation must be connected directly to the pump
outlet port. If the adapter supplied with the pump is to
be used, cut off the 3/4" and 1" sockets.
