Table Of Contents; General Information; Symbols Used In This Document - Grundfos Unilift CC 5 Installation And Operating Instructions Manual

English (GB) Installation and operating instructions
Original installation and operating instructions
These installation and operating instructions
describe Grundfos Unilift CC 5, CC 7 and CC 9.
Sections 1-3 give the information necessary to be
able to unpack, install and start up the product in a
safe way.
Sections 4-8 give important information about the
product, as well as information on service, fault
finding and disposal of the product.
CONTENTS
1. General information
1.1 Symbols used in this document
2. Installing the product
2.1 Location
2.2 Mechanical installation
2.3 Electrical connection
3. Starting up the product
3.1 Venting the product
3.2 Manual operation
3.3 Automatic operation with float switch
3.4 Pumping to low water level
3.5 Thermal protection
4. Product introduction
4.1 Product description
4.2 Intended use
4.3 Pumped liquids
4.4 Identification
5. Servicing the product
5.1 Maintaining the product
5.2 Service kits
6. Fault finding the product
7. Technical data
7.1 Operating conditions
7.2 Electrical data
7.3 Mechanical data
7.4 Dimensions and weights
8. Disposing of the product
Prior to installation, read this document
and the quick guide. Installation and
operation must comply with local
regulations and accepted codes of good
practice.
2
This appliance can be used by children
aged from 8 years and above and by
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use
of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
Page

1. General information

2
2

1.1 Symbols used in this document

3
1.1.1 Warnings against hazards involving risk of
3
death or personal injury
4
6
DANGER
6
Indicates a hazardous situation which, if
7
not avoided, will result in death or serious
7
personal injury.
7
WARNING
7
7
Indicates a hazardous situation which, if
not avoided, could result in death or
8
serious personal injury.
8
8
CAUTION
8
Indicates a hazardous situation which, if
8
not avoided, could result in minor or
9
moderate personal injury.
9
The text accompanying the three hazard symbols
9
DANGER, WARNING and CAUTION is structured in
10
the following way:
11
SIGNAL WORD
11
Description of hazard
11
Consequence of ignoring the warning.
12
- Action to avoid the hazard.
12
12
1.1.2 Other important notes
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
