Appendix C.4. Regarding Subnets and Subnet Masks

RFC standards allocate the IP Address range of 192.0.0.0 through to 223.255.255.255 to be used in
Class-C subnetting (namely subnets listed as 255.255.255.xxx, where xxx can vary based on filtering
required).
Consequently, the IP stack for this product will not allow any IP Addresses in this range to be allocated a
subnet that does not fall within the Class C range.

Appendix C.5. Securing QuickServer with Password

Access to the FieldServer can be restricted by enabling a password on the FS-GUI Passwords page –
click Setup and then Passwords in the navigation panel. There are 2 access levels defined by 2 account
names: Admin and User.
•
The Admin account has unrestricted access to the FieldServer.
•
The User account can view any FieldServer information, but cannot make any changes or restart
the FieldServer.
The password needs to be a minimum of eight characters and is case sensitive.
If the password is lost, click cancel on the password authentication popup window, and e-mail the
password recovery token to
Monitor support team. This will allow access to the FieldServer in order to set a new password.
support@sierramonitor.com

Figure 28: FS-GUI Passwords Page

Figure 29: Password Recovery Page

Page 55 of 60
QuickServer Start-Up Guide
to receive a temporary password from the Sierra
