Appendix B.32. Kamstrup 402 Mappings to
BACnet and Modbus
Point Name BACnet
Energy_T_WH_1
Energy_T_WH_2
Energy_T_WH_3
Energy_T_WH_4
Energy_T_WH_5
Energy_T_WH_6
Energy_T_WH_7
Energy_T_WH_8
Energy_T_WH_9
Energy_T_WH_10 AI 10
Temp_Flow_1 AI 11
Temp_Flow_2 AI 12
Temp_Flow_3 AI 13
Temp_Ret_1 AI 14
Temp_Ret_2 AI 15
Temp_Ret_3 AI 16
Temp_Dif_1 AI 17
Temp_Dif_2 AI 18
Temp_Dif_3 AI 19
Time_Op_Hrs_1 AI 20
Time_Op_Hrs_2 AI 21
Time_Op_Hrs_3 AI 22
Power_W_1 AI 23
Power_W_2 AI 24
Power_W_3 AI 25
Vol_Flo_L_H_1 AI 26
Vol_Flo_L_H_2 AI 27
Vol_Flo_L_H_3 AI 28
Volume_1 AI 29
Volume_2 AI 30
Volume_3 AI 31
Volume_4 AI 32
Volume_5 AI 33
Volume_6 AI 34
Volume_7 AI 35
Volume_8 AI 36
Volume_9 AI 37
Volume_10 AI 38
Time_Pt_1 AI 39
Time_Pt_2 AI 40
Time_Pt_3 AI 41
Time_Pt_4 AI 42
Time_Pt_5 AI 43
Time_Pt_6 AI 44
Time_Pt_7 AI 45
Time_Pt_8 AI 46
Time_Pt_9 AI 47
Time_Pt_10 AI 48
Status_Byte AI 49
Modbus
AI 1 30001/30002
AI 2 30003/30004
AI 3 30005/30006
AI 4 30007/30008
AI 5 30009/30010
AI 6 30011/30012
AI 7 30013/30014
AI 8 30015/30016
AI 9 30017/30018
30019/30020
30021/30022
30023/30024
30025/30026
30027/30028
30029/30030
30031/30032
30033/30034
30035/30036
30037/30038
30039/30040
30041/30042
30043/30044
30045/30046
30047/30048
30049/30050
30051/30052
30053/30054
30055/30056
30057/30058
30059/30060
30061/30062
30063/30064
30065/30066
30067/30068
30069/30070
30071/30072
30073/30074
30075/30076
30077/30078
30079/30080
30081/30082
30083/30084
30085/30086
30087/30088
30089/30090
30091/30092
30093/30094
30095/30096
30097
