RS-232 Connection R2 Port (only available on FS-QS-122X Models)

TX
RX
SG

Figure 14: RS-232 R2 Connection Port

Refer to
Appendix A2
for further hardware connection options.
The following Baud Rates are supported on the R2 Port:
4800, 9600, 19200, 38400, 57600, 115200
