11V) to the alarm panel. To avoid hardware damage, fully discharged or never used battery should be charged initially using proper charger. Latest EC declaration of conformity and product approval certificates can be downloaded from our Web site www.satel.pl...
Page 3
CA-4v1 SATEL CA-4V1 panel description The alarm panel CA4-v1 is designed for small alarm systems. It is made in advanced microchip technology in accordance with the latest trends in burglary signaling. Its features: • new generation, interference-resistant microchip, • 4 programmable parametrical zones, •...
T400mA AC AC AUX +OUT1- +OUT2- COM CLK DATA +KEY Z1 COM Z2 Z3 COM Z4 Figure 1. View of CA-4v1 control panel main board BOARD TERMINALS: module power supply inputs (17...24V AC) – detectors power supply output (+12V DC) –...
Page 5
Connection of keypad The CA-4v1 control panel interfaces with LED keypads. The keypad should be connected to the system with a four-wire line. If the panel is meant to work with several keypads, they should be connected in parallel (up to tree keypads can be connected to the panel with the guarantee of its error-free operation).
Page 6
F2 and F3 fuses to +OUT1 and +OUT2 terminals. The -OUT1 and -OUT2 terminals are cut off in inactive state, in active state (alarm signaling) they are shorted to ground (0V). Control panel CA-4v1 AC AC AUX +OUT1- +OUT2- COM CLK DATA +KEY Z1 COM Z2...
CA-4v1 SATEL Description of the LED keypad Figure 5. View of a LED Keypad Sound signals produced by the keypad a) While working with the keypad the following sounds may be generated: 1 short – key pressed confirmation, 2 short –...
SATEL CA-4v1 TROUBLE (yellow color) – blinking LED indicates a failure in the alarm system The type of trouble can be identified with function 7. 1…4 (red color) LEDs indicating the status of system zones: – − ON – zone violated, −...
Page 9
CA-4v1 SATEL The access code 4 can be used once only (the panel clears it after one-time entry). The access codes 2, 3 and 4 can be cleared by pressing the [#] key immediately after activating the service programming mode.
SATEL CA-4v1 LEDs will indicate which of the functions are activated (a LED on signals activity of a function). The number of the function to be blocked or unblocked should be entered. After unblocking of the chosen functions the [#] key should be pressed. The following functions are possible: •...
Page 11
CA-4v1 SATEL FUNCTION 0 – exit service mode Activating sequence: 0.#... FUNCTION 1 – service code programming Activating sequence: 1.#... Example: programming new code: 89354 8.9.3.5.4.#... FUNCTION 2 – permanent zone bypassing Activating sequence: 2.#... Example 1: bypassing zone number 2 and 3 2.3.#...
Page 12
SATEL CA-4v1 access code 3 not pre-programmed access code 4 not pre-programmed service code 12345 zones bypassed none zones delayed 24 hour zones exit delay time 5 seconds entry delay time 10 seconds alarm time at OUT1 5 seconds alarm time at OUT2 10 seconds Activating sequence: 9.#..
CA-4v1 SATEL Technical description main board supply voltage..................AC 17...24V control panel DC power supply rated voltage ..........DC 13.6...13.8 V DC power supply total current efficiency................1A backup power supply ..................battery 12V/7Ah battery charging current (changeover)................250mA panel power consumption....................23mA keypad power consumption ....................32mA guaranteed capacity of keypad output...............3 keypads...
Page 14
SATEL CA-4v1 TABLE OF PROGRAMMING – functions available after entering service code End of service mode Service code Permanent bypassed zones 24-hour zones Delayed zones (enter/exit) 00–99 seconds Exit delay time Entry delay time 00–99 seconds 001–999 seconds Alarm time at OUT1 000 –...
