  • Page 1 USER MANUAL GDAŃSK ca5u_en 08/08...
  • Page 2 (European Union Directives 91/157/EEC and 93/86/EEC). Latest EC declaration of conformity and product approval certificates can be downloaded from web site www.satel.pl DEFINITIONS OF SOME TECHNICAL TERMS AS USED IN THIS MANUAL: • Service mode – the control panel condition which permits calling of the service functions and programming of the security system parameters.

  • Page 3: Table Of Contents

    CONTENTS 1. T ..............2 ECHNICAL RELIABILITY OF THE SECURITY SYSTEM 2. A ..................2 LARM SYSTEM OPERATING COSTS 3. G ......................2 ENERAL FEATURES 4. O ........................... 3 PERATION 4.1 LED F ........................4 UNCTIONS 4.2 S ............5 TATUS OF CONTROL PANEL ARMED ZONES IN KEYPAD 4.3 C ..............5...

  • Page 4: Technical Reliability Of The Security System

    3. G ENERAL FEATURES The CA-5 alarm control panel is an advanced, microprocessor based device designed for burglary and panic alarm systems. It is characterized by simplicity of operation, legibility of information for the user, and a high operational reliability. It has been fitted with a telephone communicator (dialer) which enables the security system to operate together with a monitoring station.

  • Page 5: Operation

    (LEDs), as well as audible signals. Fig. 1. CA-5 KLED-S keypad The LCD keypads are available in two versions i.e. (CA-5 KLCD-L and CA-5 KLCD-S) that differ in their overall dimensions and the display size. The backlighting of keypad and display can be permanent or switched on automatically by pressing a key, or, alternatively, by violation of any control panel zone when in armed mode –...

  • Page 6: Led Functions

    CA-5 ANUAL Note: Access to all functions of the control panel in version 2.10 is provided by: LCD keypads in program version 1.08 and later, and CA-5 KLED-S keypads in version1.1 and later. 4.1 LED F UNCTIONS The LED indicators inform the user about the security system status: (red color) –...

  • Page 7: Status Of Control Panel Armed Zones In Lcd Keypad

    CA-5 SATEL Some of the LED indicators are only installed in the LED type keypads, their functions in the LCD keypads being taken over by the display. 4.2 S TATUS OF CONTROL PANEL ARMED ZONES IN KEYPAD The first five characters (counting from the left) in the LCD display lower line indicate the state of detectors attached to the control panel armed zones.

  • Page 8: Events Signaled On The Out1 Output

    RMED ODE OF THE ONTROL ANEL In order to adjust the security system to various situations, the CA-5 control panel offers several armed modes: 4.6.1 Full armed mode The operating mode when detectors connected to the control panel control the protected site and violation of the protected areas is signaled by the control panel with any available means (monitoring, sirens, keypad).

  • Page 9: Silent Armed Mode

    CA-5 SATEL 4.6.2 Silent armed mode The supervision mode during which the alarms are transmitted to the monitoring station, signaled in the keypad, and on the K type of output. EYPAD ALARM 4.6.3 Partial armed mode with no exit from the site The armed mode with automatic bypassing of the zones (detectors) assigned by the installer.

  • Page 10: Disarming And Alarm Clearing [Code][#]

    CA-5 ANUAL • the panel is not ready to arm the system – which is signaled by the panel with three long beeps (see description in the previous paragraph of this manual); • the function is disabled by the installer – this situation will be signaled with two long beeps.

  • Page 11: Alarm Memory Review [5]

    CA-5 SATEL 04.07 14:01 zo.5 Tamper alarm Fig. 3. Example of events description. The event description contains: date – day and month time of event – hour and minutes source code (if possible) – kpd. keypad – zo.n, n=1,2,..,5 – zone number, –...

  • Page 12: Current Trouble Check Out

    CA-5 ANUAL set are indicated by the number of a lit up LED, whereas troubles relating to the second set are indicated by the number of an extinguished LED (one of five). The previous (earlier) troubles are available for readout by consecutively pressing any key of the keypad, except for the [ * ] key which cancels the trouble memory review function.

  • Page 13: Switching The Chime O N /Off [8]

    CA-5 SATEL Problems with access to settings memory – may occur when the RESET pins on the control panel main board are shorted. If the pins are open, and connecting the power off and on does not clear the trouble signaling, intervention of the service personnel is necessary.
  • Page 14 CA-5 ANUAL LED keypad The panel confirms entering the user function mode by the slowly blinking [PROGRAM] LED. Next , press the key with the number of selected function and then the [#] key. LCD keypad The panel confirms entering the user functions mode with three short beeps and displays the two first names out of the currently accessible user functions.

  • Page 15: Start Download [Code][ * ][0][#]

    CA-5 SATEL code, confirm it with the [ * ] key, select the function number and confirm it by pressing the [#] key. • Refusal to perform the function is signaled with three long beeps (e.g. after calling the function 2, when all the access codes are already entered).

  • Page 16: Add User [Code][ * ][2][#]

    CA-5 ANUAL In the LED keypad the number of the lit up LED (1–5) indicates which access code is being changed. When changing the master code or the service code none of the LEDs 1–5 is on. EXAMPLE: changing the access code from 1234 to 7890.

  • Page 17: Bypass Zones [Code][ * ][4][#]

    CA-5 SATEL EXAMPLE: deleting the third and fifth user's access codes (Master user code = 7890). [7][8][9][0][ ] – calling the "user function" mode, confirmed with three short beeps and in the LED keypad additionally slow blinking of the [PROGRAM] LED, [3] [#] calling the "erase user"...

  • Page 18: Arm Silent [Code][ * ][5][#]

    The history of events may be downloaded by means of the LCD keypad or the computer and its program managing the CA-5 alarm control panel. The programming procedure is as follows: - HOURS, MINUTES –...

  • Page 19: Mono Outputs [Code][ * ][7][#]

    CA-5 SATEL Digits are presented in the binary code according to the table: LED INDICATIONS LED No. DIGIT – LED off – LED on EXAMPLE: checking the time and date of the panel clock (user access code = 1230) – next to the keys are shown examples of LED indications.

  • Page 20: Bi Outputs [Code][ * ][8][#]

    CA-5 ANUAL 6.9 BI [CODE][ * ][8][#] OUTPUTS The purpose of the function is determined by the installer. It can be used, for example, for switching on the external lighting or any electrical devices. The function is active when the BI type is selected for one of the outputs.
  • Page 21 CA-5 SATEL program the access time, call the function, enter two digits to indicate the time (using zero in the beginning for numbers smaller than 10) and press the [#] key. Two zeros entered with this function (for the number of hours) automatically block the access.

  • Page 22: History Of Manual Updates

    CA-5 ANUAL 7. HISTORY OF MANUAL UPDATES The changes described refer to the manual drawn up for the CA-5 v1.09 control panel. ERSION ESCRIPTION OF CHANGES New designations (pictograms) have been introduced for the keypad LEDs. The way of indicating the entry delay countdown in the keypad has been changed (p. 5).
  • Page 23 SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND Tel. +48 58 320 94 00 info@satel.pl www.satel.pl...
