Quantum DXi4520 Installation And Configuration Manual

Dxi4000 series
Hide thumbs Also See for DXi4520:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
READ THIS FIRST
THIS DOCUMENT PROVIDES
INSTALLATION INSTRUCTIONS FOR
YOUR DXi4000 SYSTEM.
IMPORTANT: READ THIS ENTIRE
INSTALLATION DOCUMENT BEFORE
YOU START TO UNPACK OR INSTALL
YOUR DXi4000 SYSTEM.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXi4520 and is the answer not in the manual?

Questions and answers

Related Manuals for Quantum DXi4520

Summary of Contents for Quantum DXi4520

  • Page 1 READ THIS FIRST THIS DOCUMENT PROVIDES INSTALLATION INSTRUCTIONS FOR YOUR DXi4000 SYSTEM. IMPORTANT: READ THIS ENTIRE INSTALLATION DOCUMENT BEFORE YOU START TO UNPACK OR INSTALL YOUR DXi4000 SYSTEM.

  • Page 3: Table Of Contents

    Locating the Mounting Position ..6 Installing the DXi4000 ....... 7 Cabling the DXi4000 ......10 This guide provides basic installation and configuration instructions for the Initial Configuration......11 Quantum DXi4000 system (see Figure 1). For more information, see the Accessing the DXi4000, Remote DXi4000 User’s Guide...

  • Page 4: Dxi4000 Configurations

    Storage capacity upgrades are enabled simply by adding a license key and rebooting the system.To purchase a storage capacity upgrade license, contact your Quantum sales representative. After you obtain the storage capacity license, refer to the section “Adding a License Key” in the DXi4000 User’s Guide...

  • Page 5: Rack Space Requirements

    • Temperature: 10 to 35 °C (50 to 95 °F) 35 °C Max, Altitude = 900 m or 2952.75 ft (28 °C Max, Altitude = 3048 m or 10,000 ft) These environmental conditions apply when the DXi4000 system is in operation. Quantum DXi4000 User’s Guide Note: For additional specifications, refer to the 67092).

  • Page 6: Taking Esd Precautions

    • Left and right slide assemblies • Product Information Guide • Document kit includes: • DXi4000 Installation and Configuration Instructions • Quantum Products Regulatory Documentation CD • User essentials document • Registration card • Terms and conditions Caution: Do NOT discard the packing materials after the system is unpacked. The packaging materials must be used if the system is relocated.
  • Page 7 DXi4000 WARNING: The DXi4000 weighs 49.5 lbs (22.5 Kg). Two people are required to lift the chassis. Figure 1 Unpacking the DXi4000 Slide rails Tie bands Chassis rails Front bezel DXi4000 Unpacking the DXi4000...

  • Page 8: Installing The Dxi4000 System

    DXi4000 Installation and Configuration Guide Installing the DXi4000 System Installing the DXi4000 in a rack consists of the following steps: Locating the Mounting Position on page 6 Installing the DXi4000 on page 7 Cabling the DXi4000 on page 10 Locating the Mounting The DXi4000 systems is designed to fit in a standard 19 inch wide rack.

  • Page 9: Installing The Dxi4000

    DXi4000 Installing the DXi4000 Installing the DXi4000 consists of the following steps: Installing the DXi4000 Rack Mounting Rails on page 7 Installing the DXi4000 Chassis on page 9 Installing the DXi4000 Rack Mounting Rails 1 Install the rack mounting rails (see Figure 3 for square holes and Figure 4...
  • Page 10 DXi4000 Installation and Configuration Guide Figure 4 Installing the Rack Mounting Rails (Round Holes) Front side of rack rails Rail teeth Back of rack Second tooth engaged Release button Rail pegs Release button Front of rack 2 Place the DXi4000 on a level surface and align the four keyhole slots on the chassis rails with the corresponding pins on the system.
  • Page 11 DXi4000 Figure 5 Installing the Chassis Chassis rails Rails Back Front Latch Installing the DXi4000 Chassis WARNING: Ensure that the system is properly supported until the chassis rails are locked into the slide rails on both sides. 1 To install the DXi4000 chassis (see Figure WARNING: The DXi4000 weighs 49.5 lbs (22.5 Kg).

  • Page 12: Cabling The Dxi4000

    DXi4000 Installation and Configuration Guide Figure 6 Installing the DXi4000 Chassis DXi4000 chassis Blue tab Slide rails extended Chassis rails Cabling the DXi4000 To cable the DXi4000 (see Figure 1 Connect a power cable to each power supply (two). Note: It is recommended that you connect each power cord to a separate AC circuit to ensure system availability in case of a power failure.

  • Page 13: Initial Configuration

    DXi4000 Figure 7 Cabling the DXi4000 Service port (not Back for customer use) iDRAC port (not Not used for customer use) Power cables Initial Configuration Before the DXi4000 is operational, you must configure the system through the remote management console. You must also configure your backup software. Configuring the DXi4000 consists of four major steps.

  • Page 14: Accessing The Dxi4000, Remote Management Console

    DXi4000 Installation and Configuration Guide Accessing the DXi4000, To access the DXi4000 remote management console: Remote Management 1 Turn on the DXi4000 system by pressing the power button located on the front of Console each chassis (see Figure Note: Wait for the system to boot before continuing with the procedure. This can take up to 30 minutes.
  • Page 15 DXi4000 3 Configure the network settings on the computer: Note: This procedure assumes you are running Windows XP on the computer. The steps might be different if you are using another operating system. a On the Windows Start menu, click Connect To > Show all connections. b Right-click the network connection that corresponds to the Ethernet port on the computer (for example, Local Area Connection), and click Properties.

  • Page 16: Completing The Getting Started Wizard

    (10.1.1.1) and that the network settings on the computer are correct. Wait five minutes, then try again. If the Login window still does not display, contact Quantum Customer Support. (Contact information is located on the last page of this document.) Continue with the next section to log on to the system and complete the Getting Started wizard.
  • Page 17 DXi4000 Figure 12 Getting Started Wizard: Welcome 2 Read the information about the wizard, and then click Next to continue. The License Agreement page displays (see Figure 13). Figure 13 Getting Started Wizard: License Agreement 3 Select the I have read and accept this License Agreement check box, and then click Next to continue.
  • Page 18 If you set up the DXi4000 using the example below, you can always change the network settings as needed at a later time. For more information, see the Quantum DXi4000 User’s Guide “Network” section in the (6-67092).
  • Page 19 DXi4000 Figure 14 Getting Started Wizard: Network Initial Configuration...
  • Page 20 6 Do not make any changes under IP Address Configuration > Interface Details unless directed by your network administrator. (For more information about the Quantum VLAN tag and MTU size options, see the “Network” section in the DXi4000 User’s Guide , 6-67092).
  • Page 21 Note: If the DXi needs to communicate with another subnet that is not reachable using the default gateway, a route must be added under the Routing Details section. (For more information about interface routing, see the Quantum DXi4000 User’s Guide “Network” section in the , 6-67092).
  • Page 22 To select a timeserver pool, you must have specified at least one DNS IP address in step 5d above. Otherwise, you must specify the IP address of the timeserver pool. For more information, see the Quantum DXi4000 User’s Guide (6-67092).

  • Page 23: Connecting The Ethernet Cables

    DXi4000 14 Review the settings you selected to make sure they are correct. If necessary, click Previous to return to a previous step to make changes 15 After you have confirmed all settings, click Finish. A message appears stating that completing the setup will restart the system. 16 Click Yes to restart the system.

  • Page 24: Creating A Typical Backup Configuration

    DXi4000 Installation and Configuration Guide Figure 18 Installing the Front DXi4000 bezel Bezels Creating a Typical Before you can begin using the DXi4000 for backups, you must configure the system for Backup Configuration NAS or Symantec™ NetBackup OST. See the following sections for detailed instructions for completing each type of configuration: •...
  • Page 25 Quantum Service and Support Web site) To enable OST on the DXi4000: 1 Download and install the Quantum OST Plug-in according to the instructions in the Quantum DXi-Series: NetBackup and Backup Exec OST Configuration Guide (6-67079).
  • Page 26 DXi4000 Installation and Configuration Guide Note: This procedure assumes you are creating a NAS share in a Windows Quantum DXi4000 User’s Guide environment. Refer to the (6-67092) for additional NAS configuration information. 1 Log on to the DXi4000 remote management console: a On a computer on the same subnet as the DXi4000, enter the IP address of the system in the Address box of a supported Web browser.
  • Page 27 DXi4000 Figure 20 NAS Wizard: Protocol 4 Select the Windows (CIFS) option, and then click Next to continue. The Windows page displays (see Figure 21). Figure 21 NAS Wizard: Windows 5 Enter information about the Windows domain: a Select the Workgroup option. b In the Domain/Workgroup Name box, enter the name of the workgroup the DXi4000 is joining.
  • Page 28 DXi4000 Installation and Configuration Guide Figure 22 NAS Wizard: Share Access 7 Enter information about the workgroup user that will be used to authenticate CIFS shares: • User Name - Enter the name of the workgroup user. • Password - Enter the password for the workgroup user. •...
  • Page 29 DXi4000 Figure 23 NAS Wizard: Add Share 10 Enter information about the new NAS share you are creating: • Name - Enter the name of the NAS share. The share will appear as this name on the Windows network. • Description - (Optional) Enter a brief description of the share. •...
  • Page 30 Here are the next steps you can take: • Quantum recommends enabling Email Reports after you install your DXi. When enabled, Email Reports periodically sends system configuration and status information to Quantum, including any software upgrades you have installed using the Software Upgrade Utility.
  • Page 31 • Support Wizard - Helps you enable licensed features on the DXi, register your system with Quantum, and perform other tasks that will aid Quantum customer support in assisting you. Note: To learn more about using the Configuration Wizards, refer to the Quantum DXi4000 User’s Guide...
  • Page 32 ©2013 Quantum Corporation. All rights reserved. Quantum and the Quantum logo are registered trademarks of Quantum Corporation and its affliates in the United States and/or other countries. All other trademarks are the property of their respective owners. Protected by Pending and Issued U.S.
