Quantum DXi4510 Installation And Configuration Manual

Dxi4500 series
Hide thumbs Also See for DXi4510:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation and Configuration Manual
DXi4500 Installation and
Configuration Guide
This guide provides basic installation and configuration instructions for the
DXi4500 system (see
Figure
Planning Guide before starting your installation. The Site Planning Guide is
included on the documentation CD provided with your DXi4500 system.
Note: Make sure to take the online training for the DXi4500 in order to
make the best use of your product. The online training is available
at
www.quantum.com/ServiceandSupport/StorageCareLearning/
Index.aspx
This instruction uses the following conventions:
Note: Notes emphasize important information related to the main topic.
Caution: Cautions indicate potential hazards to equipment and are
included to prevent damage to equipment.
WARNING: Warnings indicate potential hazards to personal safety and
are included to prevent injury.
Figure 1 DXi4500 System
1). Make sure to read the DXi4500 Site
DXi4500 Installation and
Configuration Guide
Contents
DXi4500 Configurations......................... 2
Choosing a Location .............................. 2
Installation Requirements.................. 2
Rack Space Requirements .................. 3
Environmental Conditions ................. 3
Taking ESD Precautions ...................... 3
Taking ESD Precautions ...................... 3
Unpacking the DXi4500 ......................... 4
Installing the DXi4500 ....................... 7
Cabling the DXi4500 ........................ 11
Initial Configuration............................. 11
Management Interface .................... 12
Configuration................................... 20
www.quantum.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXi4510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quantum DXi4510

Summary of Contents for Quantum DXi4510

  • Page 1: Table Of Contents

    Note: Make sure to take the online training for the DXi4500 in order to Configuration........20 make the best use of your product. The online training is available www.quantum.com/ServiceandSupport/StorageCareLearning/ Index.aspx This instruction uses the following conventions: Note: Notes emphasize important information related to the main topic.

  • Page 2: Dxi4500 Configurations

    DXi4520 (4.4 TB Usable Capacity) 1 TB Choosing a Location Quantum recommends installing the DXi4500 system in a controlled or restricted area to prevent access by untrained personnel. In addition, Quantum recommends that system installation be performed only by qualified IT personnel.

  • Page 3: Rack Space Requirements

    • Temperature: 10 to 35 °C (50 to 95 °F) 35 °C Max, Altitude = 900 m or 2952.75 ft (28 °C Max, Altitude = 3048 m or 10,000 ft) These environmental conditions apply when the DXi4500 system is in operation. Quantum DXi4500 User’s Guide Note: For additional specifications, refer to the (PN 6- 66904) located on the documentation CD.

  • Page 4: Unpacking The Dxi4500

    DXi4500 Installation and Configuration Guide • Avoid touching connectors and other components. Note: Dry climates and cold-weather heating environments have lower relative humidity and are more likely to produce static electricity. Unpacking the DXi4500 By following these instructions, you help ensure that the system will continue to be safeguarded after it arrives at the installation site.
  • Page 5 DXi4500 Installation and Configuration Guide Figure 2 Unpacking the DXi4500 Slide rails Tie bands Chassis rails Front bezel DXi4500 Unpacking the DXi4500...

  • Page 6: Installing The Dxi4500 System

    DXi4500 Installation and Configuration Guide Installing the DXi4500 System Installing the DXi4500 in a rack consists of the following steps: Locating the Mounting Position on page 6 Installing the DXi4500 on page 7 Cabling the DXi4500 on page 11 Locating the Mounting The DXi4500 systems is designed to fit in a standard 19 inch wide rack.

  • Page 7: Installing The Dxi4500

    DXi4500 Installation and Configuration Guide Installing the DXi4500 Installing the DXi4500 consists of the following steps: • Installing the DXi4500 Rack Mounting Rails • Installing the DXi4500 Chassis Installing the DXi4500 Rack Mounting Rails 1 Install the rack mounting rails (see Figure 4 for square holes and Figure 5...
  • Page 8 DXi4500 Installation and Configuration Guide Figure 5 Installing the Rack Mounting Rails (Round Holes) Front side of rack rails Rail teeth Back of rack Second tooth engaged Release button Rail pegs Release button Front of rack 2 Place the DXi4500 on a level surface and align the four keyhole slots on the chassis rails with the corresponding pins on the system.
  • Page 9 DXi4500 Installation and Configuration Guide Figure 6 Installing the Chassis Chassis rails Rails Back Front Latch Installing the DXi4500 System...
  • Page 10 DXi4500 Installation and Configuration Guide Installing the DXi4500 Chassis WARNING: Ensure that the system is properly supported until the chassis rails are locked into the slide rails on both sides. 1 To install the DXi4500 chassis (see Figure WARNING: The DXi4500 weighs 49.5 lbs (22.5 Kg). Two people are required to lift the chassis.

  • Page 11: Cabling The Dxi4500

    DXi4500 Installation and Configuration Guide Cabling the DXi4500 To cable the DXi4500 (see Figure 1 Connect a power cable to each power supply (two). Note: It is recommended that you connect each power cord to a separate AC circuit to ensure system availability in case of a power failure. 2 Do NOT connect Ethernet cables at this time.

  • Page 12: Accessing The Dxi4500, Remote Management Interface

    DXi4500 Installation and Configuration Guide Note: If you attempt to install multiple DXi4500 systems at the same time, an IP address conflict can occur because each system is configured with the same default IP address (10.1.1.1). To avoid this problem, install one system and configure it to use a different IP address before you connect another system to the network.
  • Page 13 DXi4500 Installation and Configuration Guide Figure 10 Ethernet Ports Ethernet port 2 Service port (not Back for customer use) Not used Not used 3 Configure the network settings on the computer: Note: This procedure assumes you are running Windows XP on the computer. The steps might be different if you are using another operating system.
  • Page 14 (10.1.1.1) and that the network settings on the computer are correct. Wait five minutes, then try again. If the Log In page still does not display, contact Quantum Customer Support. (Contact information is located on the last page of this document.) Continue with the next section to log on to the system and complete the Setup Wizard.

  • Page 15: Completing The Setup Wizard

    DXi4500 Installation and Configuration Guide Figure 12 Log In Screen Completing the Setup To complete the DXi4500 setup wizard: Wizard 1 On the Log In page, select Administrator, type password for the password, and click Login. The License Agreement page displays (see Figure 13).
  • Page 16 3 Under Segmentation, select BOND ALL (Not segmented). BOND ALL (Not segmented) is the default setting. Note: Refer to the Quantum DXi4500 User’s Guide (PN 6-66904) located on the documentation CD for information about additional segmentation options. 4 Under Bonding, select Round Robin (Mode 0). Round Robin (Mode 0) is the default setting.
  • Page 17 DXi4500 Installation and Configuration Guide 5 Click Next. The General page displays (see Figure 15). Figure 15 Network Configuration (General) 6 On the General page: a Enter the Hostname used to identify the DXi4500 system. b If your site uses Domain Search Path (DNS), enter the DNS. DNS may be either a single domain name or a comma-separated list (no spaces) of up to 6 domain names.
  • Page 18 DXi4500 Installation and Configuration Guide Figure 16 Network Configuration (IP) 8 On the IP page: Your network administrator will provide you with the IP address information. Caution: Make sure you enter the correct IP address information and that you write this information down. If you enter the incorrect IP address information and reboot, you will not be able to access the system.

  • Page 19: Connecting The Ethernet Cables

    Note: You can also choose to synchronize the system time with an NTP time server. For more information, refer to the Quantum DXi4500 User’s Guide (PN 6-66904) located on the documentation CD. 12 Select the Timezone. 13 Select the desired time format (24 hours or 12 hours).

  • Page 20: Creating A Typical Backup Configuration

    DXi4500 Installation and Configuration Guide Figure 18 Connecting the Ethernet Cables Service port (not for customer use) Not used Not used Ethernet ports Creating a Typical Before you can begin using the DXi4500 for backups, you must configure the system for Backup Configuration NAS or Symantec™...
  • Page 21 • Quantum OST plug-in (downloaded separately through the remote management pages or from the Quantum Service and Support Web site) To enable OST on the DXi4500: 1 Download and install the Quantum OST Plug-in according to the instructions in the Quantum : Symantec™ Veritas NetBackup OST Configuration Guide...
  • Page 22 Note: Do not use this procedure if you are using OST to perform backups. Instead, see OST Configuration on page 21. Note: This procedure assumes you are creating a NAS share in a Windows Quantum User’s Guide environment. Refer to the DXi4500...
  • Page 23 DXi4500 Installation and Configuration Guide Figure 19 Windows Domain Page a In the Domain Type box, select Workgroup. b In the Domain/Workgroup Name box, type the name of the Windows workgroup to join. c Click Apply A confirmation message appears. Click Yes to confirm, then click OK to continue.
  • Page 24 DXi4500 Installation and Configuration Guide Figure 20 Add NAS Share Page a In the Name box, type a name for the NAS share. The share will appear as this name on the Windows network. b Under Protocol, select Export using CIFS. c Ensure that the Enable Deduplication check box is selected (deduplication is enabled by default).
  • Page 25 • To configure your backup application to begin performing backups to the new NAS share, refer to your backup application documentation. • To enable remote replication of the NAS share to another DXi™-Series system, Quantum refer to Chapter 11, “Implementing a Data Replication Plan” in the DXi4500 User’s Guide...
  • Page 26 ©2010 Quantum Corporation. All rights reserved. Quantum, the Quantum logo, and all resellers, OEMs and other suppliers to meet customers’ evolving other logos are registered trademarks of Quantum Corporation or of their respective owners. data protection needs. Protected by Pending and Issued U.S. and Foreign Patents, including U.S. Patent No. 5,990,810.
