Settings

General

Settings for the Fronius String Control 100/12 are made in the "Fronius Solar.access" soft-
ware.

Initial Steps

-
-
-
Possible Settings (1)
for the Fronius
(2)
String Control
(3)
100/12
Strings per Mea- Indication of the number of solar module strings for each measuring channel.
suring Channel This results in automatic compensation of measuring channel deviations, which would only
be required if there were a different number of strings per channel.
Install Fronius Solar.access software on a PC
Administration / Create PV System
PV Systems / [System Name] / Settings / String Control
Select the number (address) of the Fronius String Control 100/12 to be set

Strings per Measuring Channel

Limit values:
- max. energy deviation in %
- threshold value in Ah per string
(1)
(2)
(3)
85
