USB-DIO96H User's Guide
P3
Pin Signal Name
1 THIRDPORTC Bit 7
3 THIRDPORTC Bit 6
5 THIRDPORTC Bit 5
7 THIRDPORTC Bit 4
9 THIRDPORTC Bit 3
11 THIRDPORTC Bit 2
13 THIRDPORTC Bit 1
15 THIRDPORTC Bit 0
17 THIRDPORTB Bit 7
19 THIRDPORTB Bit 6
21 THIRDPORTB Bit 5
23 THIRDPORTB Bit 4
25 THIRDPORTB Bit 3
27 THIRDPORTB Bit 2
29 THIRDPORTB Bit 1
31 THIRDPORTB Bit 0
33 THIRDPORTA Bit 7
35 THIRDPORTA Bit 6
37 THIRDPORTA Bit 5
39 THIRDPORTA Bit 4
41 THIRDPORTA Bit 3
43 THIRDPORTA Bit 2
45 THIRDPORTA Bit 1
47 THIRDPORTA Bit 0
49 VDD
P4
Pin Signal Name
1 FOURTHPORTC Bit 7
3 FOURTHPORTC Bit 6
5 FOURTHPORTC Bit 5
7 FOURTHPORTC Bit 4
9 FOURTHPORTC Bit 3
11 FOURTHPORTC Bit 2
13 FOURTHPORTC Bit 1
15 FOURTHPORTC Bit 0
17 FOURTHPORTB Bit 7
19 FOURTHPORTB Bit 6
21 FOURTHPORTB Bit 5
23 FOURTHPORTB Bit 4
25 FOURTHPORTB Bit 3
27 FOURTHPORTB Bit 2
29 FOURTHPORTB Bit 1
31 FOURTHPORTB Bit 0
33 FOURTHPORTA Bit 7
35 FOURTHPORTA Bit 6
37 FOURTHPORTA Bit 5
39 FOURTHPORTA Bit 4
41 FOURTHPORTA Bit 3
43 FOURTHPORTA Bit 2
45 FOURTHPORTA Bit 1
47 FOURTHPORTA Bit 0
49 VDD
Table 14. P3 pin-out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
Table 15. P4 pin-out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
4-6
Signal Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Signal Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Specifications
