USB-DIO96H User's Guide
P1
Pin Signal Name
1 FIRSTPORTC Bit 7
3 FIRSTPORTC Bit 6
5 FIRSTPORTC Bit 5
7 FIRSTPORTC Bit 4
9 FIRSTPORTC Bit 3
11 FIRSTPORTC Bit 2
13 FIRSTPORTC Bit 1
15 FIRSTPORTC Bit 0
17 FIRSTPORTB Bit 7
19 FIRSTPORTB Bit 6
21 FIRSTPORTB Bit 5
23 FIRSTPORTB Bit 4
25 FIRSTPORTB Bit 3
27 FIRSTPORTB Bit 2
29 FIRSTPORTB Bit 1
31 FIRSTPORTB Bit 0
33 FIRSTPORTA Bit 7
35 FIRSTPORTA Bit 6
37 FIRSTPORTA Bit 5
39 FIRSTPORTA Bit 4
41 FIRSTPORTA Bit 3
43 FIRSTPORTA Bit 2
45 FIRSTPORTA Bit 1
47 FIRSTPORTA Bit 0
49 VDD
P2
Pin Signal Name
1 SECONDPORTC Bit 7
3 SECONDPORTC Bit 6
5 SECONDPORTC Bit 5
7 SECONDPORTC Bit 4
9 SECONDPORTC Bit 3
11 SECONDPORTC Bit 2
13 SECONDPORTC Bit 1
15 SECONDPORTC Bit 0
17 SECONDPORTB Bit 7
19 SECONDPORTB Bit 6
21 SECONDPORTB Bit 5
23 SECONDPORTB Bit 4
25 SECONDPORTB Bit 3
27 SECONDPORTB Bit 2
29 SECONDPORTB Bit 1
31 SECONDPORTB Bit 0
33 SECONDPORTA Bit 7
35 SECONDPORTA Bit 6
37 SECONDPORTA Bit 5
39 SECONDPORTA Bit 4
41 SECONDPORTA Bit 3
43 SECONDPORTA Bit 2
45 SECONDPORTA Bit 1
47 SECONDPORTA Bit 0
49 VDD
Table 12. P1 pin-out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
Table 13. P2 pin-out
Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
20
32
34
36
38
40
42
44
46
48
50
4-5
Signal Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Signal Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Specifications
