USB-DIO96H User's Guide
Board label Signal name
A0 P1A0 (FIRSTPORTA Bit 0)
A1 P1A1 (FIRSTPORTA Bit 1)
A2 P1A2 (FIRSTPORTA Bit 2)
A3 P1A3 (FIRSTPORTA Bit 3)
A4 P1A4 (FIRSTPORTA Bit 4)
A5 P1A5 (FIRSTPORTA Bit 5)
A6 P1A6 (FIRSTPORTA Bit 6)
A7 P1A7 (FIRSTPORTA Bit 7)
B0 P1B0 (FIRSTPORTB Bit 0)
B1 P1B1 (FIRSTPORTB Bit 1)
B2 P1B2 (FIRSTPORTB Bit 2)
B3 P1B3 (FIRSTPORTB Bit 3)
Port 1
B4 P1B4 (FIRSTPORTB Bit 4)
B5 P1B5 (FIRSTPORTB Bit 5)
B6 P1B6 (FIRSTPORTB Bit 6)
B7 P1B7 (FIRSTPORTB Bit 7)
C0 P1C0 (FIRSTPORTC Bit 0)
C1 P1C1 (FIRSTPORTC Bit 1)
C2 P1C2 (FIRSTPORTC Bit 2)
C3 P1C3 (FIRSTPORTC Bit 3)
C4 P1C4 (FIRSTPORTC Bit 4)
C5 P1C5 (FIRSTPORTC Bit 5)
C6 P1C6 (FIRSTPORTC Bit 6)
C7 P1C7 (FIRSTPORTC Bit 7)
5V 5V
GND GND
A0 P2A0 (SECONDPORTA Bit 0)
A1 P2A1 (SECONDPORTA Bit 1)
A2 P2A2 (SECONDPORTA Bit 2)
A3 P2A3 (SECONDPORTA Bit 3)
A4 P2A4 (SECONDPORTA Bit 4)
A5 P2A5 (SECONDPORTA Bit 5)
A6 P2A6 (SECONDPORTA Bit 6)
A7 P2A7 (SECONDPORTA Bit 7)
B0 P2B0 (SECONDPORTB Bit 0)
B1 P2B1 (SECONDPORTB Bit 1)
B2 P2B2 (SECONDPORTB Bit 2)
B3 P2B3 (SECONDPORTB Bit 3)
Port 2
B4 P2B4 (SECONDPORTB Bit 4)
B5 P2B5 (SECONDPORTB Bit 5)
B6 P2B6 (SECONDPORTB Bit 6)
B7 P2B7 (SECONDPORTB Bit 7)
C0 P2C0 (SECONDPORTC Bit 0)
C1 P2C1 (SECONDPORTC Bit 1)
C2 P2C2 (SECONDPORTC Bit 2)
C3 P2C3 (SECONDPORTC Bit 3)
C4 P2C4 (SECONDPORTC Bit 4)
C5 P2C5 (SECONDPORTC Bit 5)
C6 P2C6 (SECONDPORTC Bit 6)
C7 P2C7 (SECONDPORTC Bit 7)
CTR CTR
GND GND

Ribbon connector and pin-outs

Connector
Compatible cables
Compatible accessory products*
* P1-P4 connectors are not accessible within the enclosure but are available for applications where the
enclosure is not required.
Table 10. Screw terminal pin out
Board label
Port 3
5V
GND
Port 4
5V
GND
Table 11. Ribbon connector specifications
P1-P4. 50-pin 0.1" IDC type box header
C-50FF-x, 50-pin ribbon cable
SSR-PB24
4-4
Signal name
A0 P3A0 (THIRDPORTA Bit 0)
A1 P3A1 (THIRDPORTA Bit 1)
A2 P3A2 (THIRDPORTA Bit 2)
A3 P3A3 (THIRDPORTA Bit 3)
A4 P3A4 (THIRDPORTA Bit 4)
A5 P3A5 (THIRDPORTA Bit 5)
A6 P3A6 (THIRDPORTA Bit 6)
A7 P3A7 (THIRDPORTA Bit 7)
B0 P3B0 (THIRDPORTB Bit 0)
B1 P3B1 (THIRDPORTB Bit 1)
B2 P3B2 (THIRDPORTB Bit 2)
B3 P3B3 (THIRDPORTB Bit 3)
B4 P3B4 (THIRDPORTB Bit 4)
B5 P3B5 (THIRDPORTB Bit 5)
B6 P3B6 (THIRDPORTB Bit 6)
B7 P3B7 (THIRDPORTB Bit 7)
C0 P3C0 (THIRDPORTC Bit 0)
C1 P3C1 (THIRDPORTC Bit 1)
C2 P3C2 (THIRDPORTC Bit 2)
C3 P3C3 (THIRDPORTC Bit 3)
C4 P3C4 (THIRDPORTC Bit 4)
C5 P3C5 (THIRDPORTC Bit 5)
C6 P3C6 (THIRDPORTC Bit 6)
C7 P3C7 (THIRDPORTC Bit 7)
5V
GND
A0 P4A0 (FOURTHPORTA Bit 0)
A1 P4A1 (FOURTHPORTA Bit 1)
A2 P4A2 (FOURTHPORTA Bit 2)
A3 P4A3 (FOURTHPORTA Bit 3)
A4 P4A4 (FOURTHPORTA Bit 4)
A5 P4A5 (FOURTHPORTA Bit 5)
A6 P4A6 (FOURTHPORTA Bit 6)
A7 P4A7 (FOURTHPORTA Bit 7)
B0 P4B0 (FOURTHPORTB Bit 0)
B1 P4B1 (FOURTHPORTB Bit 1)
B2 P4B2 (FOURTHPORTB Bit 2)
B3 P4B3 (FOURTHPORTB Bit 3)
B4 P4B4 (FOURTHPORTB Bit 4)
B5 P4B5 (FOURTHPORTB Bit 5)
B6 P4B6 (FOURTHPORTB Bit 6)
B7 P4B7 (FOURTHPORTB Bit 7)
C0 P4C0 (FOURTHPORTC Bit 0)
C1 P4C1 (FOURTHPORTC Bit 1)
C2 P4C2 (FOURTHPORTC Bit 2)
C3 P4C3 (FOURTHPORTC Bit 3)
C4 P4C4 (FOURTHPORTC Bit 4)
C5 P4C5 (FOURTHPORTC Bit 5)
C6 P4C6 (FOURTHPORTC Bit 6)
C7 P4C7 (FOURTHPORTC Bit 7)
5V
GND
