IntesisBox IBOX-BAC-MBTCP-100 User Manual page 19

®
IntesisBox BACnet/IP Server - Modbus TCP Master
Description Modbus TCP data format for the point.
Values
Device Specific:
Restrictions 1 bit format can only be used with digital Modbus TCP codes (1,2,5 and 6)
All the other formats cannot be used with the abovementioned codes
Edit mode Single / Multiple Values selection.
Formats 1 to 9 are generic Modbus TCP data formats while formats 10 to 20
Comments
are Device specific.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
1. 1 bit.
2. 16 bits uns: 16 bits unsigned.
3. 16 bits sig: 16 bits signed. The MSbit represents the sign.
4. 16 bits sig C2:16 bits signed (two's complement).
5. 32 bits uns: 32 bits unsigned.
6. 32 bits sig: 32 bits signed.
7. 32 bits sig C2: 32 bits signed (two's complement).
8. 32 bits IEEE: IEEE Standard for Floating-Point Arithmetic (IEEE 754).
9. 32 bits IEEE inv: 32 bits IEEE inverted (LSB..MSB).
10. 32 bits IEEE Winv: 32 bits IEEE word inverted (LSW..MSW).
11. 16 bits digital: Bit coded into 16 bits register.
12. 32 bits Mod10K uns: Integer N as 2 16-bit integers A and B. where
N= (A * 10.000) + B
13. 48 bits Mod10K uns: Integer N as 3 16-bit integers A, B and C where
2
N= (A * 10.000
14. 64 bits Mod10K uns: Integer N as 4 16-bit integers A, B, C and D
where N= (A * 10.000
15. 32 bits Mod10K sig: as the unsigned but the MSb represents the sign.
16. 48 bits Mod10K sig: as the unsigned but the MSb represents the sign.
17. 64 bits Mod10K sig: as the unsigned but the MSb represents the sign.
18. 32 bits Mod10K ION: to be used with ION devices.
19. 32 bits ION sig: to be used with ION devices.
20. 32 bits Invertomatic: to be used with Invertomatic devices.
21. MSB*100 + LSB.
Format
) +(B * 10.000) + C
3
) + (B * 10.000
User's Manual r1 eng
2
) +(C * 10.000) + D
URL http://www.intesis.com
Email info@intesis.com
tel +34 938047134
19 / 27
