Installation Instructions
1
Gasket between the mounting backplate and the exhaust duct
spacer
2
Duct spacer, exhaust
3
Gasket between the exhaust duct spacer and the back panel
4
Mounting plate
Illustration 1.7 Installing the Duct Spacers
MI92J102
In-back/Out-back Cooling Kit for VLT®
Parallel Drive Modules
VLT® Series FC 102, FC 202, and FC 302
5
Gasket between the mounting backplate and the intake duct spacer
6
Duct spacer, intake
7
Gasket between the intake duct spacer and the back panel
–
–
Danfoss A/S © 04/2016 All rights reserved.
9
