Installation Instructions
1
M5x12 screws
2
Upper duct assembly
3
Upper mounting point for drive module (M10 pem nut)
4
Mounting backplate
Illustration 1.6 Installing the Drive Modules onto the Mounting Backplate
MI92M102
In-bottom/Out-top Cooling Kit for VLT®
Parallel Drive Modules
VLT® Series FC 102, FC 202, and FC 302
5
Lower mounting point for drive module (M10 pem nut)
6
Gasket between back exhaust and mounting backplate
7
Slot gasket
–
–
Danfoss A/S © 04/2016 All rights reserved.
