Summary of Contents for Leica Lino ML90

  • Page 1 Leica Lino ML90, ML180...

  • Page 2: Table Of Contents

    Start up Version 785880b Inserting / replacing batteries English Lino ML90/180: Turn the release screw on the Congratulations on your purchase of the Leica Lino battery compartment a 1/4 turn (clock wise) with ML Series. the help of a coin or a flat head screw driver to Before starting up the instrument unlock the battery compartment.

  • Page 3: Start Up

    +10°C to +20°C/+50°F to +68°F if possible. • It is normal for the battery to become warm during charging. Start up Leica Lino ML series 785880c en...
  • Page 4 3 LED blinks: connected but not charging, online operation possible 4 Jack for battery charger WARNING: Using a battery charger not recommended by Leica Geosystems can destroy the batteries. This can cause fire or explosions. Precautions: Only use chargers recommended by Leica Geosystems to charge the batteries.

  • Page 5: Interface

    Falling below or exceeding the permissible tempera- ture range: The laser switches off and all LEDs flash. Environmental conditions might lead to shut off of the laser before the actual operation temperature limits are reached. Interface Leica Lino ML series 785880c en...

  • Page 6: Operation

    The plumb beam will be on upon start up of the unit and will automaticly turn off after 180 sec. To switch the plumb beam back on short press any mode key 2 and 3 (see page 4). Leica Lino ML series 785880c en Operation...
  • Page 7 The lines of the Lino ML are permanently pulsed and are compatible with the range of recom- mended Leica laser receivers.  See section "Working with receivers" on page 9. Operation Leica Lino ML series 785880c en...
  • Page 8 Applications Leica Lino ML series 785880c en Operation...
  • Page 9 Manual fine adjustment of vertical lines The Lino ML90 and ML180 lasers feature the possi- bility to manually turn the unit 360° around its center axis and the possibility to fine adjust the unit by ± 4° turning around the plumb axis. On the ML180 the fine adjustment can be set to its 0°...

  • Page 10: Working With Receivers

    Display status symbols Working with receivers Leica RVL100 The Leica RVL100 is a robust and easy to use laser receiver and can be used with all Leica Lino line lasers. Keypad RVL100 RVL100 1 Sensitivity : fine ±1 mm (default) 2 Sensitivity : coarse ±3 mm...
  • Page 11 Leica XCR Catch The Leica XCR Catch is a combined laser receiver and remote control for the Leica Lino ML180. Keypad 1 ON/OFF key 2 Beeper key 3 Sensitivity key 4 Auto alignment key - Press 2 sec 5 Direction key down...
  • Page 12 5 Alignment activated 6 Battery: empty 7 Battery status: medium 8 Battery status: full 9 Beep high AT Beep low AK Beep off AL Move receiver down AM Move receiver up XCR Catch Leica Lino ML series 785880c en Working with receivers...
  • Page 13 If you want to pair another Leica XCR Catch with your laser you will need to redo the pairing Lino procedure as described below.
  • Page 14 Pre-align the laser (V line) within ± 4° of the XCR Catch desired final alignment position. Remotely align the laser with the direction ± 4° keys 1. ± 1.4m @ 20m ± 4.5ft @ 65ft Lino ML180 XCR Catch LASER Leica Lino ML series 785880c en Working with receivers...
  • Page 15 2 or press the On/Off button. The auto alignment process will move the laser unit until it is precisely aligned with the Leica XCR Catch receiver. When the receiver detects the exact position it will sound a beep for 2 sec. and will display the lighted green LED 4 and the middle position.
  • Page 16 2 again for 2 sec. ± 4.5ft @ 65ft The auto alignment process will move the laser unit until it is precisely aligned with the Leica XCR Catch receiver. When the receiver detects the exact position it will beep for 2 sec.

  • Page 17: Checking The Accuracy

    Checking the accuracy Checking the accuracy of the Leica Lino ML90 and ML180 laser unit  Check the accuracy of your Leica Lino regu- larly and particularly before important measuring tasks. Checking the accuracy of the levelling Then place the instrument at the same elevation as close as possible to wall A and again mark the hori- zontal laser line on wall A (->...
  • Page 18 Now read off the maximum deviation of the laser line exceed 3 mm, then the Leica Lino is within tolerance. from the top of the plumb line. If the difference does not exceed 2 mm, then the Leica Lino is within toler- ance. Leica Lino ML series 785880c en...
  • Page 19 Checking the accuracy of the vertical plumbing the laser beam hits point A1 exactly. If point B2 is no further than 2 mm away from point B1, then the Leica Set up the instrument on an even and flat surface.

  • Page 20: Technical Data

    Technical data Leica Lino ML90 and ML180 Lino ML90 Lino ML180 Operation range * (with receiver at up to 100 m 328 ft up to 100 m 328 ft the center of the line) Self leveling accuracy 0.7 mm @10 m 1/32 inch @30 ft 0.7 mm @10 m 1/32 inch @30 ft (@25°C/77°F)
  • Page 21 NiMH battery pack NiMH charger/adapter (part no. 784966) (part no. 784967) Input voltage 3.3 V Input voltage 100-240 V AC 50-60 Hz Input current Output voltage 3.3 V Charge time Output current Technical data Leica Lino ML series 785880c en...

  • Page 22: Care And Transport

    • Do not repack until everything is completely dry. Cables and Plugs • Keep plugs clean and dry. • Blow away any dirt lodged in the plugs of the connecting cables. Care and transport Leica Lino ML series 785880c en...

  • Page 23: Safety Instructions

     The Leica Lino is designed for use in areas perma- Important paragraphs which must be adhered nently habitable by humans. Do not use the product to in practice as they enable the product to be used in explosion hazardous areas or in aggressive envi- in a technically correct and efficient manner.
  • Page 24 WARNING measurements. The Leica Lino conforms to the most stringent Refer to section "Checking the accuracy of the Leica requirements of the relevant standards and regula- Lino". Safety instructions Leica Lino ML series 785880c en...
  • Page 25 Yet, the possibility of it causing interference in WARNING other devices cannot be totally excluded. Changes or modifications not expressly approved by Leica Geosystems for compliance could void the user's authority to operate the equipment. FCC Statement, Applicable in U.S. WARNING...
  • Page 26 It is a Class 2 laser product in accordance with: Laser classification • IEC 60825-1: 2014-03 "Radiation safety of laser The Leica Lino produces visible laser beams, which are products" emitted from the instrument: Laser Class 2 products: Lino ML90 Do not stare into the laser beam or direct it towards other people unnecessarily.
