IMPORTANT
The control panel is indispensable for operating the
unit and must be installed; do not use devices othet
than the control panel supplied with the unit since
they might not be compatible with the generator.
Make the connections with the battery disconnected.
CAUTION
The control panel is provided with a connecting
cable 10 metres long. This cable should not be
modified since it might cause the panel circuit to
function incorrectly.
4.3. A.C. Connection
This connection can be done through the power terminal
board (fig. 15, ref. 1) placed inside the derivation box.
This range includes the possibility of use both at 110V
50Hz - 120V 60Hz and 220V 50Hz - 240V 60Hz.
For this reason it is possible to make two types of
connection (and use), according to the following
configurations.
1 - Parallel configuration: in this configuration there is a
single output at 110 (120) V between points P
connecting the outputs of the alternator (P
as shown in the diagram in fig. 16.
2 - Serial connection; in this configuration it is possible
to use a voltage of 220 (240) V between points P
F , as shown in the diagram in fig. 17.
2
In serial connection, power can be picked up both at 110
(120) V between points F
V between points P and F
1
in the diagram in fig. 18.
It is also possible to feed two separate lines as shown in
fig. 19 on the outputs P
1
N.B. In this case the power which can be taken from each of
the two outputs is half the rated nominal power.
- 16 -
1
, F
1 1
- F and P - P and at 220 (240)
1 2 1 2
at the same time, as shown
2
- F and P - F .
1 2 2
1
and F ,
2
, P , F )
2 2
and
1
IS 3.5 - 4.0 - 5.0 - 6.0
2
5
4
3
1
Fig. 14
Fig. 15
Fig. 16
Fig. 17
