MODEL# 23120909
OPERATOR'S MANUAL
ASSEMBLY OPERATION MAINTENANCE
MANUAL PART#: Q0436
FastCat Pro
H-Series
(23120909)
PTO GRASS
R
COLLECTION
SYSTEM
REV: 4

Advertisement

Table of Contents
loading

Related Manuals for Peco Pro2B+ 23120909

Summary of Contents for Peco Pro2B+ 23120909

  • Page 1 P P P P P P P PTO GRASS COLLECTION PECO PECO PECO PECO PECO PECO SYSTEM MODEL# 23120909 FastCat Pro H-Series OPERATOR’S MANUAL ASSEMBLY OPERATION MAINTENANCE MANUAL PART#: Q0436 (23120909) REV: 4...

  • Page 2: Table Of Contents

    RESIDENTIAL BAGGING SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2-14 Weight Kit Assembly Installation - - - - - - - - - - - 11 Safety Alert Symbols - - - - - - - - - - - - - - - - - - - - - - 3 2-15 Length of Hose Adjustment - - - - - - - - - - - - - - 12...

  • Page 3: Safety Alert Symbols

    SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.

  • Page 4: Warranty

    PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or before the expiration of the original warranty period, whichever is later.

  • Page 5: Introduction And Description

    Remove the D-drive spacer using an arbor press or Section I equivalent. On removal, adjacent bearing OUTER race must be supported or bearing damage may occur. Refer INTRODUCTION & DESCRIPTION to Figure 2-1b. 1-1 Introduction PRESS Your grass collection system has been designed to give Figure 2-1b you a low maintenance, simple, and effective way to collect the grass clippings from your mower.

  • Page 6: Left & Right Frame Bracket Installation

    Remove the rear bumper shown in Figure 2-1e from the Figure 2-2b mower frame. Keep the hardware for use later in the installation. (1) 3/8”-16 x 1” HHCS (1) 3/8”-16 Locknut Figure 2-1e Remove Rear Bumper Right Frame Bracket Existing Hardware 2-3 Lower Frame Assembly Installation...

  • Page 7: Pto Mount Plate Component Installation

    Insert the PTO stop plate P#(B0733) between the left 2-4 PTO Mount Plate Component and right PTO mount plates as shown in Figure 2-4c. Installation Secure the PTO stop plate to the left and right PTO mount plates using (4) 1/4”-20 x 3/4” HHCS P#(K1222) and (4) 1/4”-20 nylon flange locknuts P#(K2014).

  • Page 8: Pto Assembly Installation

    Loosen the (2) 5/16”-18 x 3/4” HHCS P#(K1153) that 2-5 PTO Assembly Installation secure the gear box to the PTO assembly, as shown in Figure 2-6b. Loosen the adjustment bolt (1) 3/8”-16 x 2” Insert the PTO assembly P#(A1840) into the mounting hex bolt P#(K0348).

  • Page 9: Blower Cone Installation

    2-10 Blower Cone 2-8 Impeller Blade Installation/Removal Removal/Replacement Fasten the blower cone P#(V0016) to the blower housing located on the PTO assembly. Use (3) 1/4”-20 x To Remove: To access the impeller blade, remove the 3/4” HHCS P#(K1222), (3) 1/4” lock washers blower cone P#(V0016) and blower cone hardware from P#(K0039), and (3) 1/4”...

  • Page 10: Upper Frame Assembly Installation

    2-9 Upper Frame Assembly 2-11 Inlet Installation Installation Insert the Inlet P#(V0019) into the hole on the top Lift the upper frame assembly P#(A0871) into position assembly from the inside and then snap the inlet into above the lower frame assembly P#(A1091) as shown in place.

  • Page 11: Boot To Mower Deck Installation

    Fasten the weight bracket P#(B1844) to the front frame 2-13 Boot To Mower Deck Installation brace using (2) 3/8”-16 x 3-1/2” u-bolts P#(K0136) and Raise the grass deflector on the mower deck. Fasten the (4) 3/8”-16 nylon flange locknuts P#(K2038). Refer to boot plate P#(B0750) to the boot P#(V1168) using (3) Figure 2-14b.

  • Page 12: Length Of Hose Adjustment

    2-15 Length Of Hose Adjustment 2-17 Lower Hose To Blower Cone The hoses in steps 2-16 and 2-17 must be cut to fit your Installation machine. Follow steps 2-16 and 2-17. do not cut the Slide a pre-assembled hose clamp P#(J0060) over both hoses until you have tried to fit them on your machine.

  • Page 13: Installation/Removal Of Collection Bags

    2-19 Installation/Removal Of Figure 2-19c Plastic Top Collection Bags IMPORTANT! To prevent bag wear, install (2) red plastic end caps P#(J0274), as shown in Figure 2-20a, on each bag ring before installing bags. Figure 2-20a Bag Ring Red Plastic End Caps Fasten Draw Completed Bag -Latch Here...

  • Page 14: Operating Instructions

    SECTION III 3-3 Disengagement Of The PTO OPERATING INSTRUCTIONS Assembly A. To disengage the PTO assembly, slide the 3-1 General Safety engagement handle out of the retaining slot and push the engagement handle away from the operator’s seat. Only qualified people familiar with this operator’s manual and the mower’s operator’s manual should operate this WARNING: The PTO assembly blades will continue to machine.

  • Page 15: Lubrication

    If for any reason your Service Center by the manufacturers to be affixed to the component. is unable to service your collection system or supply replacement parts, contact PECO Inc. and include the 3. Check belt for proper tension. following information on the chart below.
  • Page 17 A1028 TOP ASSEMBLY A0871 UPPER FRAME ASSEMBLY EXPLODED PARTS VIEW Item # Doc # Title A0871 2 BAG FRAME ASSY. V0017 PRO 2 BAGGER TOP V0018 Black Plastic Screen J4009 SHORT RUBBER STRAP W/ S HOOK K1030 1/4"-20 x 1-1/4" CARRIAGE BOLT K0037 1/4"...
  • Page 18 A2194 PTO BASE ASSEMBLY EXPLODED PARTS VIEW...
  • Page 19 A2194 PTO BASE ASSEMBLY EXPLODED PARTS VIEW DESCRIPTION...
  • Page 20 A1840 PTO ASSEMBLY EXPLODED PARTS VIEW DESCRIPTION...

  • Page 21: Safety Decals

    SAFETY DECALS To promote safe operation, PECO Inc. supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. P P P P P P P...
  • Page 23 NOTES...
  • Page 24 P P P PECO PECO PECO PECO PECO 10 WALDEN DRIVE ARDEN, NORTH CAROLINA 28704 (800) 438-5823 OR (828) 684-1234 FAX: (828) 684-0858 EMAIL: peco@lawnvac.com WEBSITE: www.lawnvac.com...

Table of Contents
