Peco Pro Series Operator's Manual

Grass collection system for ferris is 1500z, ferris is 2000z
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P
P P P
P
PECO
PECO
PECO
PECO
PECO
FERRIS IS 1500Z
MODEL: #41721205, #417212013
OPERATOR'S MANUAL
ASSEMBLY
MANUAL PART#: Q0379
ProSeries
ProSeries
Pro 12
Pro 12
DESIGNED FOR:
MODEL: #41721207, #41721214
OPERATION
$10.00
GRASS COLLECTION
SYSTEM
ENGINE DRIVEN
FERRIS IS 2000Z
MAINTENANCE
REV: 1

Advertisement

Table of Contents
loading

Related Manuals for Peco Pro Series

Summary of Contents for Peco Pro Series

  • Page 1 ProSeries ProSeries P P P GRASS COLLECTION PECO PECO PECO PECO PECO SYSTEM Pro 12 Pro 12 ENGINE DRIVEN DESIGNED FOR: FERRIS IS 1500Z FERRIS IS 2000Z MODEL: #41721205, #417212013 MODEL: #41721207, #41721214 OPERATOR’S MANUAL ASSEMBLY OPERATION MAINTENANCE MANUAL PART#: Q0379 $10.00...

  • Page 2: Table Of Contents

    PECO GRASS COLLECTION SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2...

  • Page 3: Safety Alert Symbols

    SAFETY WARNING! NEVER operate the unit unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.

  • Page 4: Warranty

    PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or before the expiration of the original warranty period, whichever is later.

  • Page 5: Introduction And Description

    Figure 2-1b shows the mower with the rear bumper 1-1 Introduction assembly and ROPS removed. We are pleased to have you as a PECO customer. Your Figure 2-1a collection system has been designed to give you a low maintenance, simple and effective way to collect the grass clippings from your mower.

  • Page 6: Lower Frame Leg Installation

    2-2 Lower Frame Leg Installation 2-3 Main Frame Assembly Installation Mount the left lower frame leg P#(B0513) and right lower NOTE: It is recommended that (2) people assist you when frame leg P#(B0512) to the outside of the rear mower installing the main frame assembly.

  • Page 7: Engine Mount Tube Installation

    2-4 Engine Mount Tube Installation 2-6 Engine/Blower/Blade Assembly Installation Fasten the engine mount tube P#(B1117) to the left and Position the engine/blower/blade assembly on top of the right lower frame legs using (2) 3/8”-16 U-Bolts engine mount arm assembly P#(A0274) and fasten using (4) P#(K1119) and (4) 3/8”-16 nyloc nut P#(K1216) as 5/16”-18 x 1-1/2”...

  • Page 8: Aluminum Grass Container Installation

    2-8 Aluminum Grass Container 2-9 Inlet Installation Installation The inlet will need to be attached to the container (Page 10). Open the container, push the inlet from the inside of NOTE: It is recommended that (3) people assist in the container through the hole in the container to the mounting the container.

  • Page 9: Boot Installation

    2-11 Boot Installation 2-12 Weight Installation Ferris 1500Z Series: Fasten the boot plate P#(B0521) Ferris 1500Z Series: Fasten the weight bracket to the boot P#(E1031) using (2) 3/8”-16 x 1” carriage P#(B0523) to the front frame of the mower using (2) bolts P#(K1182) and (2) 3/8”-16 nyloc nuts P#(K1216).

  • Page 10: Blower Cone Installation

    2-14 Impeller Blade 2-13 Blower Cone Installation Removal/Replacement Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of (2) 5/16”-18 x 2-1/2” HHCS P#(K0125). Now partially thread the bolts into each of the two tabs located on the WARNING blower housing. Place blower cone so the two tabs line up with the bolts then tighten completely.

  • Page 11: Length Of Hose Adjustment

    2-15 Lengths Of Hose Adjustment 2-17 Lower Hose To Blower Cone Installation The hoses in steps 2-16 and 2-17 must be cut to fit your machine. Follow steps 2-16 and 2-17. Do not cut the Slide a hose clamp P#(J0070 or J0080) over both ends hoses until you have tried to fit them on your machine.

  • Page 12: Exploded Parts View And Drawings

    Lift Handle Assembly Figure -12. Aluminum Grass Container Assembly INLET RING Figure-10. Aluminum Grass Container With Handle Attached Figure-11. Latch Hook Mechanism Assembly...
  • Page 13 Aluminum Grass Container Exploded View...

  • Page 18: Operating Instructions

    * Watch your speed- Normal conditions will allow a been torn or worn through, replace with genuine speed of up to approximately 5 mph, but thick, heavy PECO parts. damp conditions will require reduced ground speed. * Mow with sharp blades- A sharp blade cuts cleaner.

  • Page 19: Parts And Service

    PECO PARTS AND SERVICE Wand Kit! With your PECO Wand Attachment you will double the 5-1 Parts And Service Information ability of your PECO Lawn Vac. Using the same powerful vacuum/blower that makes your Lawn Vac work...

  • Page 20: Safety Decals

    SAFETY DECALS To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part #: R4027 Part #: R1053...
  • Page 22 P P P PECO PECO PECO PECO PECO 10 WALDEN DRIVE ARDEN, NORTH CAROLINA 28704 (800) 438-5823 OR (828) 684-1234 FAX: (828) 684-0858 EMAIL: peco@lawnvac.com WEBSITE: www.lawnvac.com...
