DEMO MANUAL DC2341A
PARTS LIST
ITEM
QTY
REFERENCE
Required Circuit Components
1
1
CIN1
2
2
CIN4, CIN5
3
1
CIN6
4
2
COUT1, COUT4
5
4
COUT2, COUT3, C15, C16
6
2
C1, C17
7
2
C2, C5, C7
8
1
C10
9
1
C11
10
1
C12
11
2
C6, C14
12
1
D1
13
1
L1
14
1
Q1
15
1
R1
16
4
R8, R16, R17, R20
17
2
R19, R30
18
1
R28
19
1
R10
20
1
R13
21
1
R4
22
2
R9, R12
23
1
R24
24
2
R3
25
1
R23
26
1
R11
27
1
R5
28
1
R32
29
1
U1
Additional Demo Board Circuit Components
30
0
COUT5, COUT6 OPT
31
0
CIN2, CIN3, (OPT)
32
0
C3, C4, C8, C9, C13, (OPT)
33
0
RN1, R2, R6, R7, R14, R15, R18, R22,
R25, R27, R29
Hardware: For Demo Board Only
34
13
E1-E13
35
1
JP2
36
1
JP1
37
4
J1-J4
38
1
J5
39
4
MH1, MH2, MH3, MH4
40
2
JP1, JP2
4
PART DESCRIPTION
CAP , ALUM ELEC180µF 20% 25V
CAP , 1210 22µF 20% 25V X5R
CAP , 1206 10µF 20% 25V X5R
CAP , 7343 330µF 20% 2.5V POSCAP
CAP , 1210 100µF 20% 6.3V X5R
CAP , 0805 1µF 10% 25V X5R
CAP , 0603 220nF 10% 25V X5R
CAP , 0603 0.1µF 10% 10V X5R
CAP , 2.2nF X7R 50V 5% 0603
CAP , 0603 120pF 10% 25V NPO
CAP , 0805 4.7µF 20% 10V X5R
DOIDE, SCHOTTKY 30V SOD-323
IND, 0.25µH
MOSFET, N-CH D-S 40V TO252
RES, 2.2Ω 1/10W 5% 0603
RES, 0Ω JUMPER 1/10W 0603
RES, 10k 1/10W 5% 0603
SENSE RES, 2512 0.01Ω 1% 1W
RES 0603 100k 1% 1/10W
RES 0603 1k 1% 1/10W
RES, 0603 619Ω 1% 1/10W
RES, 0603 10Ω 5% 1/10W
RES, 0603 6.04k 1% 1/10W
RES, 0603 2.7Ω 1% 1/10W
RES, 0603 124k 1% 1/10W
RES, 0603 3.01k 1% 1/10W
RES, 0603 3.09k 1% 1/10W
RES, 0603 6.65k 1% 1/10W
IC, LTC7130EY#PBF
CAP , 7343 OPTION
CAP , OPTION
CAP , 0603 OPTION
RES, 0603 OPTION
TESTPOINT, TURRET, 0.094" PbF
HEADER, 4 PIN 0.079" SINGLE ROW
HEADER, 3 PIN 0.079" SINGLE ROW
JACK, BANANA
CONN, BNC, 5 PINS
STAND-OFF , NYLON 0.50" tall
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
PANASONIC., 25SVPF180M
AVX, 12103D226MAT2A
AVX, 12063D106MAT2A
PANASONIC, 2R5TPE330M9
AVX, 12106D107MAT2A
AVX, 08053D105KAT2A
MURATA GRM188R71E224KA88D
AVX, 0603ZD104KAT2A
AVX, 06035C222JAT2A
AVX, 06033A121KAT2A
AVX, 0805ZD475MAT2A
CENTRAL SEMI., CMDSH-3 TR
WURTH ELEKTRONIK, 744308025
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW06032R20JNEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310K0JNEA
VISHAY, WSL2512R0100FEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW0603619RFKEA
VISHAY, CRCW060310R0JNEA
VISHAY, CRCW06036K04FKEA
VISHAY, CRCW06032R7FKEA
VISHAY, CRCW0603124KFKEA
VISHAY, CRCW06033K01FKEA
VISHAY, CRCW06033K09FKEA
VISHAY, CRCW06036K65FKEA
LINEAR TECH., LTC7130EY#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN041PAEN-RC
SULLINS, NRPN031PAEN-RC
KEYSTONE 575-4
CONNEX, 112404
KEYSTONE, 8833
SAMTEC, 2SN-BK-G
dc2341af
