Replacing The Return Switch - Pitco SG Series Solstice Service Manual

Pitco Solstice and Solstice Supreme High Efficiency Gas Fryers
Replacing the Return Switch
1. Disconnect all the wires from the gas valve,
pilot, and SCB valve.
2. Drop the gas valve from the manifold.
3. Remove the two (2) screws, which hold the
return valve handle, using a 5/16 inch socket.
4. Remove the return valve handle bracket.
SG/SSH Series Service Manual
5. Remove the two (2) screws, which hold the
mounting bracket, using a 5/16 inch socket
6. Remove the mounting bracket.
7. Disconnect the mounting bracket wire from the
pump box (not shown).
72
