Replacing the Basket Lift Components
Removing the Basket Lift Cover
1. Remove the six (6) screws, which hold the back
of the basket lift cover, using a 5/16 inch socket.
Replacing the Transformer
1. Remove the two (2) screws, which hold the
transformer, using a 5/16 inch socket.
SG/SSH Series Service Manual
2. Lift up the back and remove.
2. Remove all wires on transformer box using
needle-nose pliers. See "Wiring Diagram –
Basket Lifts" on page 91.
3. Follow steps 1 through 2 in reverse to reinstall
new transformer box.
44
