Pitco SG Series Solstice Service Manual page 42

Pitco Solstice and Solstice Supreme High Efficiency Gas Fryers
14. Remove the splash back by lifting up.
15. Remove the six (6) screws, which hold the tank
to the cabinet, using a 5/16 inch socket.
SG/SSH Series Service Manual
16. Remove the channel strip by pulling up.
17. Score the silicon sealer between the tanks using
a flathead screwdriver or utility knife.
18. Remove high-limit and temperature probes. See
"Replacing the Hi-Limit Thermostat" on page
58.
19. Remove the two (2) screws, which hold the top
deck support, using a 5/16 inch socket.
42
