Replacing the Spinal Tap
1. Remove the two (2) screws in the front of the
unit, which hold the entrance box assembly,
using a 5/16 inch socket.
2. Cut the zip ties from the cord retainers.
3. Unplug the cords from the electrical entrance
box assembly.
SG/SSH Series Service Manual
4. Remove the two (2) screws, which hold the
spinal harness, using a /16 socket.
5. Remove the entrance box assembly.
6. Remove the front panel assembly. See
"Replacing the Controllers and Wiring Harness"
on page 20.
7. Disconnect all the connections and remove the
harness from front panel.
25
