Replacing the Controllers and Wiring Harness
Removing the Controller Front Panel Bezel
1. Remove the two (2) screws on the controller
panel using a Phillips screwdriver.
2. Pull out the controller panel front bezel.
SG/SSH Series Service Manual
3. Disconnect the controller wiring harness.
4. Remove the four (4) screws on the back side of
the bezel using a 3/8 inch nut driver.
