Altronix AL624TE220 Installation Instructions

AL624TE220 power supply/charger converts 220VAC input into 12VDC @ 1.2A of continuous supply current (see speci-
fications). This general purpose power supply has a wide range of applications for access control, security, and CCTV
system accessories that require additional power.
Input:
• 220VAC, 50/60Hz, 0.25A.
Output:
• 12VDC output.
• 12VDC @ 1.2A supply current.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when AC fails.
• Maximum charge current 0.3A.
• PTC battery protection.
1. Mount AL624 into power supply enclosure with nylon fasteners (Figs. 1-3, pg. 2) (four (4) supplied).
2. Mount power supply unit enclosure in the desired location.
3. Connect blue and yellow leads from transformer secondary to the terminals marked [AC].
4. Connect 220VAC power to the black and white flying leads of the transformer.
5. Unit is factory set for 12VDC output.
6. Measure output voltage before connecting devices. This helps avoiding potential damage.
7. Connect devices to be powered to the terminals marked [+ DC] and [DC - BAT], carefully observing polarity.
8. Connect battery to the terminals marked [BAT +] and [DC - BAT] (battery leads included)
Note: When batteries are not used, a loss of AC will result in a loss of output voltage.
LED Diagnostics:
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
Terminal Identification:
Terminal Legend Function/Description
AC/ AC Low voltage AC input (T1656220).
- DC + 12VDC @ 1.2A continuous supply current.
+ BAT - Stand-by battery connections. Maximum charge rate 300mA.
AL624TE220
Power Supply / Charger

Overview:

Specifications:
Installation Instructions:
Power Supply Status
Normal operating condition.
Loss of AC, Stand-by battery supplying power.
No DC output. Short circuit or thermal overload condition.
No DC output. Loss of AC. Discharged or no battery present.
Visual Indicators:
• AC input and DC output LED indicators.
Features:
• Power supply/charger with enclosure and T1656220
transformer (16.5VAC/56VA).
• Extremely compact design.
• Includes battery leads.
Enclosure Dimensions (H x W x D approx.):
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm).
