Altronix AL624ET Installation Instructions

The AL624ET Linear Power Supply / Charger converts a 115VAC 60Hz input to a low voltage DC output.
This general purpose power supply has a wide range of applications for access control, security and CCTV system
accessories that require additional power.
Agency Listing:
• CE European Conformity.
Input:
• 115VAC, 60 Hz 1.2A.
Output:
• 12VDC @ 1.2A supply current.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when AC fails.
• Maximum charge current 0.3A.
• PTC battery protection.
Output
12VDC @ 1.2A
continuous supply current
1. Mount AL624 board in the enclosure (see reverse).
2. Unit is factory set for 12VDC.
3. Connect a proper transformer to the terminals marked [AC] (refer to voltage output/transformer selection table).
Use 18 AWG or larger for all power connections (Battery, DC output).
Keep power-limited wiring separate from non power-limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum 0.25" spacing must be provided.
4. Measure output voltage before connecting devices. This helps avoiding potential damage.
5. Devices to be powered should be connected to the terminals marked [+ DC] and [DC – BAT], carefully observing polarity.
6. Connect battery to the terminals marked [BAT +] and [DC – NEG] (battery leads included)
Note: When batteries are not used, a loss of AC will result in a loss of output voltage.
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
AL624ET
Linear Power Supply / Charger

Specifications:

Voltage Output/Transformer Selection Table:

Voltage Selector (JMPR) Transformer
Leave J1 and J2 Intact
Installation Instructions:

LED Diagnostics:

Power Supply Status
Normal operating condition.
Loss of AC, Stand-by battery supplying power
No DC output. Short circuit or thermal overload condition.
No DC output. Loss of AC. Discharged or no battery present.

Overview:

Visual Indicators:
• AC input and DC output LED indicators.
Features:
• Power supply/charger with enclosure and TP1620
plug-in transformer (16.5VAC/20VA).
• Fits one (1) 12VDC/7AH or
two (2) 12VDC/4AH batteries.
Mechanical:
• Enclosure Dimensions (H x W x D approx.):
8.5" x 7.5" x 3.5" (215.9mm x 190.5mm x 88.9mm)
• Board dimensions (W x L x H): 2.5" x 3" x 1.5"
(63.5mm x 76.2mm x 38.1mm)
16.5VAC / 20VA (Altronix model TP1620)
