Figures - Altronix AL624TE220 Installation Instructions

Fig. 1: AL624
FACTORY SET AT 12V
CUT J1 FOR 24V
CUT J2 FOR 6V
J1
J2
AC
Fig. 2: Enclosure
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIAL624TE220 - Rev. 081015
AC AC +DC - BAT +
STEP 1: Use these holes to mount
AL624 by pushing the
nylon fasteners
(fig. 3) through the back
of the enclosure. Nylon
fasteners will snap
into place.
Fig. 3:
Nylon Fastener
DC
Springlock
I25Q
White
Lead
220VAC input
Black
50/60Hz,
Lead
0.25A
MEMBER
