ALRLBV Series
Sub-Assembly
Power Supply/Charger Boards
with LED Cable Assembly
Models Include:
AL400RLBV
- 12 or 24VDC @ 4A
AL600RLBV
- 12 or 24VDC @ 6A
Installation Guide
Rev. ALRLBV-070324
AL1012RLBV
- 12VDC @ 10A
AL1024RLBV
- 24VDC @ 10A
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALRLBV Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altronix ALRLBV Series

  • Page 1 ALRLBV Series Sub-Assembly Power Supply/Charger Boards with LED Cable Assembly Models Include: AL400RLBV AL1012RLBV - 12 or 24VDC @ 4A - 12VDC @ 10A AL600RLBV AL1024RLBV - 12 or 24VDC @ 6A - 24VDC @ 10A Installation Guide More than just power.
  • Page 2: Specifications

    Overview: Altronix RLBV power supply/chargers convert a 220VAC / 60Hz input to a 12VDC or 24VDC output. Specifications: Output Voltage (Current) Altronix Input Rating Model 220VAC Input Battery Maximum 12VDC 24VDC Number 50/60Hz Fuse Rating Fuse Rating Charge Current AL400RLBV 1.5A...
  • Page 3 Stand-by Specifications: AL400RLBV: Burg. Application Fire Applications Access Control Output 4 hr. of Stand-by/ 24 hr. of Stand-by/ 60 hr. of Stand-by/ Applications 5 min. of Alarm 5 min. of Alarm 5 min. of Alarm* Stand-by Stand-by = 4.0A Stand-by = 1.0A Stand-by = 300mA 12VDC / 40AH Battery 4 hrs./4A...
  • Page 4: Installation Instructions

    Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, the Canadian Electrical Code and with all local codes and authorities having jurisdiction. Product is intended for indoor use only. 1. Refer to Sub-Assembly Installation Instructions for mounting Rev. MS020119. 2.
  • Page 5: Maintenance

    Fig. 2 - LED Cable Harness Connection Fig. 2a - AL400RLBV Fig. 2b - AL600RLBV Fig. 2c - AL1012RLBV Fig. 2d - AL1024RLBV White AC LOCAL Lead Lead White White White Lead Lead Lead Lead Lead Lead Wiring: Use 18 AWG or larger for all low voltage power connections. Note: Take care to keep power-limited circuits separate from non power-limited wiring (220VAC, Battery).
  • Page 6: Terminal Identification

    Terminal Identification: Terminal Legend Function/Description L, G, N Connect 220VAC to these terminals: L to hot, N to neutral (Fig. 1a, pg. 4). AL400RLBV: 12VDC @ 4A or 24VDC @ 3A continuous output (Power-Limited output) (Fig. 1d, pg. 4). AL600RLBV: 12VDC or 24VDC @ 6A continuous output (Non Power-Limited output) (Fig.
  • Page 7 Model Reference Chart: Sub-Assembly Board Enclosures AL400RLBV Trove1R and Trove2R AL600RLBV Trove1R and Trove2R AL1012RLBV Trove1R and Trove2R AL1024RLBV Trove1R and Trove2R ALRLBV Power Supply/Chargers Installation Guide - 7 -...
  • Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIALRLBV G03X MEMBER - 8 - ALRLBV Power Supply/Chargers Installation Guide...

This manual is also suitable for:

Al400rlbvAl600rlbvAl1012rlbvAl1024rlbv
