The electrical installation must be carried out according to the appropriate regulations (e.g.
cable cross-sections, fuses, PE connection). Additional information can be obtained from the
documentation.
The documentation contains information about installation in compliance with EMC (shielding,
grounding, filters and cables). These notes must also be observed for CE-marked controllers.
The manufacturer of the system or machine is responsible for compliance with the required limit
values demanded by EMC legislation.

1.1.5 Operation

Systems including controllers must be equipped with additional monitoring and protection devices
according to the corresponding standards (e.g. technical equipment, regulations for prevention
of accidents, etc.). You are allowed to adapt the controller to your application as described in the
documentation.
Pictograph
1.2 Reference Documentation
• SV01, SMVector Operating Instructions, Technical Library: http://www.lenzeamericas.com
• AN0022, Getting Started with CANopen (PS & SMV Drives), Technical Library: http://www.lenzeamericas.com
• CiA Specifications, EN 50325-4, CAN in Automation: http://www.can-cia.org
DANGER!
• After the controller has been disconnected from the supply voltage, live components
and power connection must not be touched immediately, since capacitors could be
charged. Please observe the corresponding notes on the controller.
• Do not continuously cycle input power to the controller more than once every three
minutes.
• Please close all protective covers and doors during operation.
WARNING!
Network control permits automatic starting and stopping of the inverter drive. The system
design must incorporate adequate protection to prevent personnel from accessing
moving equipment while power is applied to the drive system.
Table 1: Pictographs used in these instructions
Signal word Meaning
DANGER! Warning of Hazardous
Electrical Voltage.
WARNING! Impending or possible
danger for persons
STOP!
Possible damage to
equipment
NOTE
Useful tip: If observed, it will
make using the drive easier
Safety Information
Consequences if ignored
Reference to an imminent danger that
may result in death or serious personal
injury if the corresponding measures
are not taken.
Death or injury
Damage to drive system or its
surroundings
