  • Page 1 SuperServer ® 6049P-E1CR45H 6049P-E1CR45L 6049P-E1CR45L+ USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................12 1.5 Motherboard Layout ......................13 Quick Reference Table ......................14 System Block Diagram ......................16 Chapter 2 Server Installation 2.1 Overview ..........................17...
  • Page 5 Preface Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................32 3.2 Accessing the System ......................32 Accessing the Motherboard ....................32 Accessing the Storage Drives ...................33 Removing the Small Top Cover/Air Shroud Assembly ............34 3.3 Installing Hot-Swappable Optional NVMe Drives ...............35 Installing the NVMe Drive Cage ..................35 Installing NVMe Drive Carriers into the NVMe Drive Cage ..........35 3.4 Motherboard Components ....................37...
  • Page 6 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Thermal Monitor ......................53 IPMI Submenu .......................54 System Info ........................54 IPMI Event Log ......................54 LCD Test ........................55 Settings Submenu ......................55 Error Message .......................55 UID Message ........................55 Chapter 4 Motherboard Connections 4.1 Power Connections ......................56 4.2 Headers and Connectors ....................57 4.3 Ports ...........................62 Rear I/O Ports ........................62 4.4 Front Control Panel ......................65...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides an outline of the functions and features of the 6049P-E1CR45H/L/L+ SuperStorage Server. This storage server is based on the X11DSC+ motherboard and the SC946LTS-R1K66P chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides an overview of the main features of the system. System Features Motherboard X11DSC+ Chassis SC946LTS-R1K66P The X11DSC+ supports dual Intel 81xx/61xx/51xx/41xx/31xx (LGA 3647) processors, which offer three Intel ® UltraPath Interconnect (UPI) of up to 10.4 GT/s. Note: Both CPUs need to be installed for full access to the PCI-E slots, DIMM slots, and onboard controllers.

  • Page 10: Server Chassis Features

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual 1.4 Server Chassis Features The SC946LTS-R1K66P is a 4U chassis. Control Panel The switches and LEDs located on the control panel are described below. Figure 1-1. Control Panel View Control Panel Features Item Feature Description The main power switch applies or removes primary power from the Power button power supply to the server but maintains standby power.

  • Page 11: Front Features

    Chapter 1: Introduction Information LED Status Description Continuously on and An overheat condition has occurred. (This may be caused by cable congestion.) Blinking red (1Hz) Fan failure, check for an inoperative fan. UID has been activated locally to locate the Solid blue server in a rack environment.

  • Page 12: Rear Features

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Rear Features Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Module 1600W power supply (redundant, with two power modules) 2.5" Drive Bays Two rear mounted 2.5" hot-swap drive bays I/O Ports I/O ports (see Section 4.3 for details) PCI Slots Three low-profile PCI slots for add-on cards...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the X11DSC+ with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. IPMI_LAN JUIDB1 COM1...

  • Page 14: Quick Reference Table

    System cooling fan headers IPMI_LAN Dedicated IPMI LAN port I-SATA0-3 SATA 3.0 connection header supported by the Intel® PCH I-SATA Ports with built-in power pins and with support of Supermicro SuperDOM (Disk On Module) I-SATA2/I-SATA3 devices I-SGPIO1 Serial Link General Purpose I/O Header...
  • Page 15 Chapter 1: Introduction Connector Description USB2 Type A USB 3.0 Header VGA Port Description Status HDD_LED1 HDD LED Green: On: HDD Normal LEDBMC BMC Heartbeat LED Blinking Green: BMC normal LEDPWR Onboard Power LED On: Onboard power on UID-LED UID (Unit Identifier) LED Solid Blue: Unit identified Memory LED Description...

  • Page 16: System Block Diagram

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual System Block Diagram JPCIE3 JPCIE1 16GB/s 32GB/s Slot 3 Slot 1 VCCP1&2 12V PCIE 3.0 x16 PCIE 3.0 x8 VR13 5+1 PHASE 205W JPCIE2 32GB/s Slot 2 PCIE 3.0 x16 PE2 PE1 DMI CPU 2 10.4G Polarity Inversion CPU 1 PE3 PE1 PE2...

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 18: Server Precautions

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 19: Circuit Overloading

    Chapter 2: Server Installation Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 20: Installing The Rails

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual 2.2 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. Do not use a two post "telco" type rack. This rail set fits a rack between 26.5" and 36.4"...

  • Page 21: Releasing The Inner Rail

    Chapter 2: Server Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. 1.

  • Page 22: Installing The Inner Rails

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Installing the Inner Rails Begin the rack mounting procedure by installing the inner rails to the chassis. 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the mushroom posts on the side of the chassis with the holes in the inner rail.

  • Page 23: Installing The Outer Rails Onto The Rack

    Chapter 2: Server Installation Installing the Outer Rails onto the Rack 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack.

  • Page 24: Adapters For Round And Threaded Hole Racks

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Adapters for Round and Threaded Hole Racks The chassis includes adapter brackets for those customers using round hole racks or racks with threaded holes size M5 or larger. Installing the Outer Rails with Adapter Brackets 1. Place the hooks of the front of the outer rail into the square holes of one of the adapter brackets.

  • Page 25: Installing The Chassis Into A Rack

    Chapter 2: Server Installation 2.3 Installing the Chassis into a Rack After the rails are installed on the chassis and on the rack, the server can be installed in the rack. It is heavy and requires two to three people or a lift. Installing the Chassis into a Rack 1.

  • Page 26: Removing The Chassis From The Rack

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack. Use a lift. 1.

  • Page 27: Installing The Cable Management Arm

    Chapter 2: Server Installation 2.5 Installing the Cable Management Arm The SC946LTS chassis supports a cable management arm (CMA) that keeps the rear cables organized and clear of the rail mechanisms when the system is extended out the front of the rack for maintenance.
  • Page 28 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Installing the Cable Management Arm 1. Slide CMA connector #1 forward onto the two posts on the rear of the right inner rail (right side when viewed from the front). It snaps into place. 2. Slide CMA connector #2 forward onto the two posts on the rear of the right middle rail. It snaps into place.
  • Page 29 Chapter 2: Server Installation 3. Slide CMA connector #3 forward onto the two posts on the rear of the left middle rail. It snaps into place. 4. For CMA connector #4, align the metal tabs with the slots on the rear of the left outer rail and push it forward.
  • Page 30 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Figure 2-10. Routing the Cables 5. Open the four red plastic caps and route the cables into the wire carrier. 6. If necessary, adjust the U-brackets to clear chassis components. Figure 2-11. Adjusting the U-Brackets...
  • Page 31 Chapter 2: Server Installation 7. Use the six Velcro straps to secure the cables to the CMA. Use a strap on either side of each joint and one on each U-bracket, inserting it through the slot on the bracket. 8. Slide the chassis forward and backward in the rack to confirm that the cable management arm is operating smoothly.

  • Page 32: Chapter 3 Maintenance And Component Installation

    Accessing the Motherboard After the system is assembled by the manufacturer, the motherboard tray can be extended no more than two inches, due to the internal cabling. Only approved Supermicro technicians should remove the tray. To install or replace components, such as PCI expansion cards or memory, open the storage compartment cover, remove any fans that are in the way, and possibly remove the small top cover/air shroud assembly.

  • Page 33: Accessing The Storage Drives

    Chapter 3: Maintenance and Component Installation Accessing the Storage Drives To access the storage drives, pull the system out of the rack, remove the two thumb screws on the right side of the chassis and lift. The cover is designed to open about 100 degrees and support itself in that position.

  • Page 34: Removing The Small Top Cover/Air Shroud Assembly

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Removing the Small Top Cover/Air Shroud Assembly 1. Open the storage compartment cover. 2. Remove both power supply modules. 3. Remove the thumb screw midway on the right side of the chassis. 4. Lift off the cover. Small Top Cover/ Air Shroud Thumb Screw...

  • Page 35: Installing Hot-Swappable Optional Nvme Drives

    Chapter 3: Maintenance and Component Installation 3.3 Installing Hot-Swappable Optional NVMe Drives The SC946S storage chassis supports the option for six 2.5" hot-swappable NVMe drives in tool less hard drive carriers, which are mounted in a fixed NVMe drive cage. The NVMe drive cage must be installed prior to removing the drives.
  • Page 36 1. Grasp the drive carrier handle and pull the carrier up and out of the NVMe cage. Warning: Enterprise level hard disk drives are recommended for use in Supermicro storage chassis and servers. For information on recommended HDDs, visit the Supermicro website at www.supermicro.com.

  • Page 37: Motherboard Components

    Chapter 3: Maintenance and Component Installation 3.4 Motherboard Components Processor and Heatsink Installation This server is sold with the CPU and heatsink installed. Only approved Supermicro technicians should perform maintenance. Memory Memory Support The 6049P-E1CR45H/L/L+ supports up to 3 TB of 3DS Load Reduced DIMM (3DS LRDIMM), 3DS Registered DIMM (3DS RDIMM), up to 2666MHz ECC SDRAM or Non-Volatile DIMM (NVDIMM) modules in 24 slots.

  • Page 38: Memory Population Guidelines

    The following memory population sequence table was created based on guidelines provided by Intel to support Supermicro motherboards. The diagram is for illustrative purposes; your motherboard may look different. Check the Supermicro website for possible updates to memory support.
  • Page 39 Chapter 3: Maintenance and Component Installation Memory Population for X11 DP Motherboard, 24 DIMM Slots When 1 CPU is used: Memory Population Sequence 1 CPU & 1 DIMM CPU1: P1-DIMMA1 1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1 1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1 1 CPU &...
  • Page 40 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Memory Population for X11 DP Motherboard, 24 DIMM Slots CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/ P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF2/P1-DIMMF1 2 CPUs & 20 DIMMs CPU2: P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/P2-DIMMD2/P2-DIMMD1/ P2-DIMME2/P2-DIMME1 CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/ 2 CPUs & 22 DIMMs P1-DIMMD2/P1-DIMMD1/P1-DIMME2/P1-DIMME1/P1-DIMMF1 (Unbalanced: not CPU2: P2-DIMMC1/P2-DIMMC2/P2-DIMMB1/P2-DIMMB2/P2-DIMMA1/P2-DIMMA2/ recommended) P2-DIMMD2/P2-DIMMD1/P2-DIMME2/P2-DIMME1/P2-DIMMF1 CPU1: P1-DIMMC1/P1-DIMMC2/P1-DIMMB1/P1-DIMMB2/P1-DIMMA1/P1-DIMMA2/ 2 CPUs &...

  • Page 41: Installing Memory

    Chapter 3: Maintenance and Component Installation Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 42: Installing Expansion Cards

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Installing Expansion Cards The system can accommodate three PCI-E 3.0 expansion cards. Installing an Expansion Card 1. Power down the system as described in Section 3.1. 2. Open the storage compartment top cover. 3. Remove the two-fan housing from the chassis rear (described in later section). 4.

  • Page 43: Motherboard Battery

    Chapter 3: Maintenance and Component Installation Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 44: Chassis Components

    Safe to remove NVMe device Amber Blinking at 1 Hz Attention state—do not remove NVMe device Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, see the Supermicro website.

  • Page 45: Adding Or Replacing Main Storage Drives

    Chapter 3: Maintenance and Component Installation Adding or Replacing Main Storage Drives Removing a Hard Drive Carrier from the Storage Compartment 1. Open the storage compartment cover. 2. Slide the release button on the drive carrier, which opens the carrier handle. 3.
  • Page 46 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Installing a 3.5" Storage Drive With the drive carrier removed from the storage compartment: 1. Under the main carrier handle, find and the lift the breakout lever and pull out the side of the carrier. Carrier Breakout Lever Pull Out Side...

  • Page 47: Storage Drives At The Chassis Rear

    Chapter 3: Maintenance and Component Installation Storage Drives at the Chassis Rear There is room for two optional hot-swap 2.5" drives in the rear of the chassis. Figure 3-9. Drives at Chassis Rear Installing 2.5" Drives at the Chassis Rear 1.

  • Page 48: Fans

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Fans The system has five hot-swap 8-cm exhaust fans accessible from the rear of the chassis. They can be removed or replaced individually by pinching the top and bottom release tabs. One or two fans should be removed to install or replace memory or PCI expansion cards. Fan speed is controlled by a system temperature setting in IPMI.
  • Page 49 Chapter 3: Maintenance and Component Installation Removing the Dual Fan Housing The housing should be removed to install PCI expansion cards. Remove the two thumb screws and pull the housing. Thumb Screws Figure 3-12. Removing the Dual Fan Housing Checking the Server Air Flow •...

  • Page 50: Power Supply Modules

    Power Supply Modules The chassis features redundant power supplies. The power modules can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. The power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v.

  • Page 51: System Status Lcd Screen

    Chapter 3: Maintenance and Component Installation 3.6 System Status LCD Screen The 6049P-E1CR45H/L/L+ offers an optional LCD screen on the front of the chassis that shows the status of many system components. The functions are described in this section. Introduction This feature gives the user the ability to monitor drives, power supplies, fans, and connections.

  • Page 52: Main Screen

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Main Screen After a welcome page, the Main screen appears. UID Alert Error Alert Throughout the GUI, component status is displayed in color where green indicates normal operation, red indicates a problem, and gray indicates the component is not installed. The UID Alert is blue when active;...

  • Page 53: Processor Status

    Chapter 3: Maintenance and Component Installation Processor Status Main Page > System Status > Processor This page displays CPU information including model (SKU), temperature and status. The status may be operational (good, green), failed (bad, red), or not installed (gray). Memory Status Main Page >...

  • Page 54: Ipmi Submenu

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual IPMI Submenu Main Page > IPMI System Info Main Page > IPMI > System Info The IPMI System Info pages show: • LCD firmware version • IPMI firmware version • BMC IP Address • MAC Address •...

  • Page 55: Lcd Test

    Chapter 3: Maintenance and Component Installation • /*MEM MRC Error*/ • /*Fan Error*/ • HDD activity LCD Test Main Page > IPMI > LCD Test Settings Submenu Main Page > Settings > Brightness This item allows the user to adjust the LCD brightness. Error Message An error message pops up whenever critical error occurs.

  • Page 56: Chapter 4 Motherboard Connections

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 57: Headers And Connectors

    Chapter 4: Motherboard Connections 4.2 Headers and Connectors Onboard Fan Header Five 4-pin fan headers (FAN1~5) are located on the motherboard to provide CPU/system cooling. These fan headers support both 3-pin fans and 4-pin fans; however, onboard fan speed control is available only when all 4-pin fans are used in the motherboard. Fan speed control is supported by a thermal management setting in the BMC (Baseboard Management Controller).
  • Page 58 Intel PCH C621 chipset, and the S-SATA ports are supported by Intel SCU. S-SATA4/S- SATA5 can be used with Supermicro SuperDOMs which are yellow SATA DOM connectors with power pins built in, and do not require external power cables.
  • Page 59 NVMe SMBus (I2C) headers (JNVI2C1/2), used for PCI-E SMBus clock and data connections, provide hot-plug support via a dedicated SMBus interface. This feature is only available for a Supermicro complete system with a Supermicro-proprietary NVMe add-on card and cable installed.
  • Page 60 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Power SMBus (I2C) Header The Power System Management Bus (I2C) header at JPI2C1 monitors the power supply input/ output voltages, fans, temperatures, and status. Refer to the table below for pin definitions. Power SMBus Header Pin Definitions Pin# Definition...
  • Page 61 Ground Ground Inlet Sensor Header This header (JSEN1) allows BMC to monitor thermal inlet temperature. A special module is required. Please contact Supermicro at www.supermicro.com to purchase the module for this header. Refer to the table below for pin definitions.

  • Page 62: Ports

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual 4.3 Ports Rear I/O Ports See Figure 4-1 below for the locations and descriptions of the various I/O ports on the rear of the motherboard. IPMI_LAN JUIDB1 COM1 (UID) JSDCARD1 UID-LED CTRL CPU2_MEMORY_LED CPU1_MEMORY_LED USB 0/1 (3.0) LEDBMC JI2C_FP1 CPU1 SIOM PCI-E 3.0 x16...
  • Page 63 Chapter 4: Motherboard Connections VGA Port The onboard VGA port is located next to IPMI LAN port on the I/O back panel. Use this connection for VGA display. Serial Port There is one COM port (COM1) on the I/O back panel. The COM port provides serial communication support.
  • Page 64 (Note: UID can also be triggered via IPMI on the motherboard. For more information, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com.) UID Switch Pin Definitions...

  • Page 65: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 66 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS - see Chapter 4).
  • Page 67 Chapter 4: Motherboard Connections NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 68: Jumpers

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual 4.5 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 69 Chapter 4: Motherboard Connections Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 70: Led Indicators

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual 4.6 LED Indicators IPMI-Dedicated LAN LEDs A dedicated IPMI LAN is located on the I/O Backplane of the motherboard. The amber LED on the right indicates activity, while the green LED on the left indicates the speed of the connection.
  • Page 71 Chapter 4: Motherboard Connections Unit ID LED A rear UID LED indicator (UID-LED) is located near the UID switch on the I/O back panel. This UID indicator provides easy identification of a system.unit that may need service. HDD LED An HDD LED indicator, located at HDD_ LED1 on the motherboard, indicates the status of onboard hard drive disks including SATA devices.

  • Page 72: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.

  • Page 73: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to create a DVD of the drivers and utilities it contains.

  • Page 74: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 75: Chapter 6 Bios

    Chapter 6: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11DSC+ motherboard(s). The is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 76: Main Menu

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2014 after RTC reset. Supermicro X11DSC+ BIOS Version This item displays the version of the BIOS ROM used in the system.

  • Page 77: Advanced Settings Menu

    Chapter 6: BIOS CPLD Version This item displays the version of the CPLD (Complex-Programmable Logical Device) used in the system. Memory Information Total Memory This item displays the total size of memory available in the system. Memory Speed This item displays the default speed of the memory modules installed in the system. 6.3 Advanced Settings Menu Use the arrow keys to select the Advanced submenu and press <Enter>...
  • Page 78 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Boot Feature  Quiet Boot Use this feature to select the screen between displaying POST messages or the OEM logo at bootup. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages. The options are Disabled and Enabled. Note: POST message is always displayed regardless of the item setting.
  • Page 79 Chapter 6: BIOS Power Configuration Watch Dog Function If enabled, the Watch Dog Timer will allow the system to reset or generate NMI based on jumper settings when it is expired for more than 5 minutes. The options are Disabled and Enabled.
  • Page 80 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual • Processor Min Ration • Microcode Revision • L1 Cache RAM • L2 Cache RAM • L3 Cache RAM • Processor 0 Version • Processor 1 Version Hyper-Threading [All] (Available when supported by the CPU) Select Enabled to support Intel®...
  • Page 81 Chapter 6: BIOS Hardware Prefetcher (Available when supported by the CPU) If this item is set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU performance. The options are Enable and Disable.
  • Page 82 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual ENERGY_PERF_BIAS_CFG Mode (Available when Power Performance Tuning is set to BIOS Controls EPB) The Energy Performance BIAS (EPB) feature allows the user to configure CPU power and performance settings. Select Maximum Performance to set the highest performance. Select Performance to optimize performance over energy efficiency.
  • Page 83 Chapter 6: BIOS CPU C State Control (Available when Power Technology is set to Custom) Autonomous Core C-State Use this feature to enable the autonomous core C-State control. The options are Dis- able and Enable. CPU C6 report Select Enable to allow the BIOS to report the CPU C6 State (ACPI C3) to the operating system.
  • Page 84 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Chipset Configuration Warning: Setting the wrong values in the following features may cause the system to malfunc- tion. North Bridge This feature allows the user to configure the settings for the Intel® North Bridge. UPI Configuration ...
  • Page 85 Chapter 6: BIOS Link L1 Enable Select Enable for the QPI to enter the L1 state for power saving. The options are Dis- able, Enable, and Auto. IO Directory Cache (IODC) Use this feature to enable the IO Directory Cache (IODC) support. The options are Dis- able, Auto, Enable for Remote InvItoM Hybrid Push, InvItoM AllocFlow, Enable for Remote InvItoM Hybrid AllocNonAlloc, and Enable for Remote InvItoM and Remote WViLF.
  • Page 86 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual LLC Dead Line Alloc Select Enable to optimally fill dead lines in LLC. Select Disable to never fill dead lines in LLC. The options are Disable, Enable, and Auto. Isoc Mode Select Enable to enable Isochronous support to meet QoS (Quality of Service) require- ments.
  • Page 87 Chapter 6: BIOS use different values for the tRWSR DDR timing settings for different channels as trained. The options are Disable and Enable. 2X Refresh Options Use this item to select the 2X refresh mode. The options are Auto and Enable. Page Policy This feature allows the user to determine the desired page mode for IMC.
  • Page 88 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual UEFI ARM Mirror Select Enable to support the UEFI-based address range mirroring with setup option. The options are Disable and Enable. Memory Rank Sparing Select Enable to enable memory-sparing support for memory ranks to improve memory performance.
  • Page 89 Chapter 6: BIOS IIO Configuration  IIO Configuration EV DFX Features When this feature is set to Enable, the EV_DFX Lock Bits that are located on a proces- sor will always remain clear during electric tuning. The options are Disable and Enable. ...
  • Page 90 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual PCI-E Port Max Payload Size Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance. The options are 128B, 256B, and Auto.  P1_NVMe2 Link Speed Use this feature to select the link speed for the PCIe port.
  • Page 91 Chapter 6: BIOS The options are Distinct and Common. If this item is set to Distinct, this component and the component at the opposite end of the Link are operating with separate refer- ence clock sources. If this item is set to Common, this component and the component at the opposite end of the Link are operating with a common clock source.
  • Page 92 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual PCI-E Port Clocking The options are Distinct and Common. If this item is set to Distinct, this component and the component at the opposite end of the Link are operating with separate refer- ence clock sources. If this item is set to Common, this component and the component at the opposite end of the Link are operating with a common clock source.
  • Page 93 Chapter 6: BIOS PCI-E Port Link Status PCI-E Port Link Max PCI-E Port Link Speed PCI-E Port Clocking The options are Distinct and Common. If this item is set to Distinct, this component and the component at the opposite end of the Link are operating with separate refer- ence clock sources.
  • Page 94 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual (Intel® IO Acceleration) IOAT Configuration  Disable TPH Select Yes to deactivate TLP Processing Hint support. The options are No and Yes. Prioritize TPH Use this feature to enable the prioritize TPH support. The options are Enable and Disable.
  • Page 95 Chapter 6: BIOS Posted Interrupt Use this feature to enable VT_D posted interrupt. The options are Enable and Disable. Coherency Support (Non-Isoch) Select Enable for the Non-Iscoh VT-d engine to pass through DMA (Direct Memory Access) to enhance system performance. The options are Enable and Disable. ...
  • Page 96 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Hot Plug Capable (Available when the device is detected by the system) Use this feature to enable the hot plug support for PCIe root ports 1A~1D. The op- tions are Disable and Enable. Intel® VMD for Volume Management Device on CPU2 ...
  • Page 97 Chapter 6: BIOS VMD Config for PStack2 Intel® VMD for Volume Management Device Select Enable to use the Intel® Volume Management Device Technology for this stack. The options are Disable and Enable. *If the item above "Intel® VMD for Volume Management Device" is set to Enable, the following items will be displayed: CPU2 SLOT2 PCI-E 3.0 x16 VMD (Available when the device is detected by the system)
  • Page 98 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Disabled and Enabled. PCIe PLL SSC Use this feature to enable PCI-E Phase-locked Loop (PLL) Spread Spectrum Clocking (SSC).
  • Page 99 Chapter 6: BIOS *If the item above "Configure SATA as" is set to AHCI, the following items will be displayed: SATA Port 0~ Port 3 This item displays the information detected on the installed SATA drive on the particular SATA port.
  • Page 100 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual SATA Port 0~ Port 3 This item displays the information detected on the installed SATA drive on the particular SATA port. • Model number of drive and capacity • Software Preserve Support Hot Plug (SATA Port 0~ Port 3) Select Enabled to enable a SATA port specified by the user.
  • Page 101 Chapter 6: BIOS Maximum Read Request Select Auto to allow the system BIOS to automatically set the maximum read request size for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes. MMCFG Base Use this feature to select the default value for the PCI MMIO (Memory-Mapped IO) base address.
  • Page 102 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual  Network Stack Configuration Network Stack Select Enabled to enable UEFI (Unified Extensible Firmware Interface) for network stack support. The options are Disabled and Enabled. *If the item above "Network Stack" is set to Enabled, the following items will be displayed: Ipv4 PXE Support Select Enabled to enable Ipv4 PXE boot support.
  • Page 103 Chapter 6: BIOS Device Settings This item displays the status of a serial part specified by the user. Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address.
  • Page 104 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 105 Chapter 6: BIOS Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Disabled and Enabled. *If the item above is set to Enabled, the following items will become available for user's configuration: Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the...
  • Page 106 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 107 Chapter 6: BIOS Console Redirection Select Enabled to use a COM port selected by the user for EMS Console Redirection. The options are Disabled and Enabled. *If the item above is set to Enabled, the following items will become available for user's configuration: Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the...
  • Page 108 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual ACPI Settings NUMA (Available when the OS supports this feature) Select Enabled to enable Non-Uniform Memory Access support to enhance system performance. The options are Disabled and Enabled. WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) platform and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.
  • Page 109 Chapter 6: BIOS Pending operation Use this item to schedule a TPM-related operation to be performed by a security device for system data integrity. Your system will reboot to carry out a pending TPM operation. The options are None and TPM Clear. Platform Hierarchy Use this item to disable or enable platform hierarchy for platform protection.
  • Page 110 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Intel® Virtual RAID on CPU (refer to Appendix E for more  information) This submenu displays the information of the Intel® VMD controllers as detected by the BIOS.

  • Page 111: Event Logs

    Chapter 6: BIOS 6.4 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  Enabling/Disabling Options SMBIOS Event Log Change this item to enable or disable all features of the SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 112 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual When Log is Full Select Erase Immediately for all messages to be automatically erased from the event log when the event log memory is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event This option toggles the System Boot Event logging to enabled or disabled.

  • Page 113: Ipmi

    Chapter 6: BIOS 6.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. When you select this submenu and press the <Enter> key, the following information will display: • IPMI Firmware Revision: This feature indicates the IPMI firmware revision used in your system.
  • Page 114 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 115 Chapter 6: BIOS • Gateway IP Address: This feature displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). • VLAN: Select Enabled to enable IPMI VLAN support. The options are Enabled and Dis- abled.

  • Page 116: Security Settings

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual 6.6 Security Settings This menu allows the user to configure the following security settings for the system. Administrator Password Press Enter to set the user password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
  • Page 117 Chapter 6: BIOS Secure Boot This feature is available when the platform key (PK) is pre-registered where the platform operates in the user mode and compatibility support module (CSM) support is disabled in the BIOS Setup utility. Select Enabled for secure boot flow control. The options are Disabled and Enabled.
  • Page 118 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual Platform Key (PK)  The Platform Key (PK), which is pre-installed in firmware during manufacturing, provides full control of the secure boot key hierarchy. The options are Save to File, Set New, and Erase.  Key Exchange Keys (KEK) The Key Exchange Key (KEK), which is held by the operating system vendor, can be updated by the holder of the PK and be used by secure boot to protect access to signa-...

  • Page 119: Boot Settings

    Chapter 6: BIOS 6.7 Boot Settings Use this feature to configure Boot Settings: Use this feature to configure Boot Settings: Boot mode select Use this item to select the type of device that the system is going to boot from. The options are LEGACY, UEFI, and DUAL.
  • Page 120 SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual • Legacy/UEFI/Dual Boot Order #3 • Legacy/UEFI/Dual Boot Order #4 • Legacy/UEFI/Dual Boot Order #5 • Legacy/UEFI/Dual Boot Order #6 • Legacy/UEFI/Dual Boot Order #7 • Legacy/UEFI/Dual Boot Order #8 • UEFI/Dual Boot Order #9 •...
  • Page 121 Chapter 6: BIOS Boot Option #1 The options are (the available hard disk drive) and Disabled. Network Drive BBS Priorities  This feature allows the user to specify which available network drives are boot devices. Boot Option #1 The options are IBA XE Slot 0100 v2398 and Disabled. ...

  • Page 122: Save & Exit

    SuperStorage Server 6049P-E1CR45H/L/L+ User's Manual 6.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 123 Chapter 6: BIOS Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS utility Program. Listed on this section are other boot options for the system (i.e., Built-in EFI shell). Select an option and press <Enter>.

  • Page 124: Appendix A Bios Error Codes

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Appendix A BIOS Error Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 125 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 126: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 127 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 128 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 129 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 130 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 131 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 132 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
  • Page 133 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 134 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 135 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 136 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 137 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 138 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 139 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 140 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 141 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 142 SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 143 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 144 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 145 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 146: Appendix C System Specifications

    SuperStorageServer 6049P-E1CR45H/L/L+ User's Manual Appendix C System Specifications Processors Single Intel 81xx/61xx/51xx/41xx/31xxin an LGA 3647 type socket Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel C621 BIOS 256 Mb AMI BIOS SPI Flash ROM ®...
  • Page 147 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Directive 2012/19/EU...

This manual is also suitable for:

Superserver 6049p-e1cr45l

Table of Contents
