Altronix ALTV615DC48CBM220 Installation Manuals page 7

• ALTV615DC44M220 • ALTV615DC44CBM220 • ALTV615DC48M220 • ALTV615DC48CBM220
1.25"
(31.75mm)
1"
(25.4mm)
8.13"
(206.5mm)
1"
(25.4mm)
1.25"
(31.75mm)
3.85"
(97.79mm)
ALTV615DC220 Series
Enclosure Dimensions for:
8.5" x 7.5" x 3.875" (215.9mm x 191mm x 98.4mm)
0.6"
(15.24mm)
0.9"
(22.86mm)
0.6"
(15.24mm)
1"
(25.4mm)
3.63"
(92.2mm)
7.25"
(184.15mm)
0.6"
(15.24mm)
0.6"
(15.24mm)
7.25"
(184.15mm)
1.25"
(31.75mm)
3.85"
(97.79mm)
0.9"
(22.86mm)
8.13"
(206.5mm)
3.85"
(97.79mm)
1"
(25.4mm)
1"
(25.4mm)
1.25"
(31.75mm)
1"
(25.4mm)
1.75"
(44.45mm)
1"
(25.4mm)
- 7 -
