Altronix ALTV615DC48CBM220 Installation Manuals page 5

Fig. 2 - ALTV615DC48M220 and ALTV615DC48CBM220
TRIMPOT
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace fuse with the same type and rating.
Do not expose unit to rain or moisture.
ALTV615DC220 Series
Output Wiring
POWER
SUPPLY
BOARD
Trimpot
Fig. 2a
Input
220VAC, 50/60Hz, 0.5A
MAIN FUSE
ON OFF
PTC
used on
ALTV615DC48CBM220
BARRIER
- 5 -
