Fig. 3 - ALTV615DC416220 • ALTV615DC416CB220 • ALTV615DC616220 • ALTV615DC61CB220
ALTV615DC1016220 • ALTV615DC1016CB220
Fig. 3a
TRIMPOT
Illuminated
Power Switch
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace fuse with the same type and rating.
Do not expose unit to rain or moisture.
- 6 -
POWER SUPPLY
BOARD
220VAC, 50/60Hz
DC OUTPUTS
1 2 3 4 5 6 7 8
PD16W
3.5A 250V
Input
9 10 11 12 13 14 15 16
N
COMMON
OUTPUTS
PROTECTED
P
OUTPUTS
PTC
used on
models with CB suffix.
Example:
ALTV615DC416CB220
ALTV615DC220 Series
