Altronix ALTV2416CB Installation Manuals page 7

Altv2416 series cctv power supplies
Hide thumbs Also See for ALTV2416CB:

Advertisement

Fig. 4 - ALTV2416600 and ALTV2416600CB
Voltage Selection
Configuration
N
P
24VAC
Output
(Yellow)
N
P
28VAC
Output
(Black)
ALTV2416 Series
MAIN FUSE
S
(Black)
S
(Yellow)
PTCs
used on
ALTV2416600CB
Illuminated
Power Switch
Input 115VAC,
50/60Hz.
- 7 -
