- Page 1 Translation of the Original Operating Instructions MAB 455...
- Page 2 Fig . 1...
-
Page 3: Table Of Contents
Dispose of the device via communal collection points. The lubricant used can contain substances dangerous to the environment. Dispose of the lubricant according to local regulations. Observe the disposal instructions from the lubricant manufacturer. MAB 455... - Page 4 . If the situation is not avoided, it may lead to material damage. ► Follow the instructions in this warning to avoid material damage. NOTE ► A note indicates additional information that simplifies the use of the machine. MAB 455...
-
Page 5: Safety
■ Pay attention to cleanliness at the workplace. ■ Keep the machine clean, dry and free of oil and grease. ■ Follow the instructions on lubricating and cooling the tool. MAB 455... - Page 6 Risk of losing one or more fingers. ► Remove loose jewellery before begin- ning work. ► Wear a hair net if you have long hair. MAB 455...
- Page 7 ► Check that the tool is tightened securely before using (see section “Inserting the tool”). ► Do not allow the connecting cable to hang over edges (trip effect). MAB 455...
- Page 8 In order to prevent the machine from starting unexpectedly after switching on the magnetic clamp again or after reconnection following interruption to the power supply ("restart protection"), the machine must be switched on using the ON/OFF switch. MAB 455...
- Page 9 Also wear the following protective equip- ment during special work: Symbol Meaning Helmet for protecting your head against falling objects Wear a harness where there is a danger of falling. Gloves for protection against injuries MAB 455...
-
Page 10: Components / Delivery Contents
Components / delivery contents Scope of supply Components / delivery con- tents Machine MAB 455 Machine overview KEYLESS quick-change drill chuck system Core drill ZAK 075 ejector pin (not supplied as standard) ZAK 100 ejector pin Tool mounting Safety chain... -
Page 11: Before Using For The First Time
(D) supplied. ► Check the safety chain for proper function before every use. A dam- aged safety chain must not be used. Replace a damaged safety chain immediately. MAB 455... - Page 12 NOTE paint, zinc and scale coatings and rust. The substrate must satisfy the following ► BDS offers a range of accessories conditions in order to achieve sufficient with special clamping devices for magnetic clamping force: tubes and non-magnetic materials.
- Page 13 Lever out the drill chuck with the ejec- ‹ tor pin (E) or loosen the drill chuck by Lever out the tool with the ejector ‹ tapping against the ejector pin. pin (E) or loosen the tool by tapping against the ejector pin. MAB 455...
-
Page 14: Using
Deactivating the magnetic clamp Hold the handle tightly (9) to stop the ‹ machine from slipping. Switch the magnet (23) ON/OFF ‹ switch off. The indicator lamp in the magnet (23) ON/OFF switch extin- guishes. MAB 455... - Page 15 To select the desired gear stage, ‹ break up the swarf. switch the machine off and set the selector lever (5) to the desired speed as shown in the table below. Gear stage Load speed Level 1 250 min Level 2 450 min MAB 455...
-
Page 16: Eliminating Blockages
Drilling with core drills does not require NOTE great force. The drilling process is not ► The BDS range of accessories accelerated by higher pressure. The includes special devices (e.g., drill wears faster and the machine can POW 200) for removing swarf. -
Page 17: Cleaning/Maintenance
Clean the tool and the tool holder on ‹ Replacement of the carbon brushes may the machine. only be carried out by BDS or by an au- Clean the guide of the machine slide. thorised specialist workshop. Unauthorised ‹ repairs will invalidate the guarantee. -
Page 18: Storage
The lubrication system does Lubricant tap closed. Open the lubricant tap. not function. Connecting nipple clogged. Clean the tank and nipple. NOTE ► If you cannot resolve the problem with the steps described above, please contact customer service. MAB 455... -
Page 19: Technical Data
Technical data Technical data Model MAB 455 Dimensions (L x W x H) 295 x 178 x 598 Magnetic foot (L x W) 168 x 84 Approx. net weight. 230 V / 50-60 Hz Operating voltage (see type plate) or 110-125 / 50-60 Hz... -
Page 20: Ec Declaration Of Conformity
EC Declaration of Conformity EC Declaration of Conformity in accordance with Machine Directive 2006/42/EC, appendix II 1A Name/address of the manufacturer: BDS Maschinen GmbH Martinstraße 108 D-41063 Mönchengladbach We hereby declare that the product: Magnetic core drilling machine Model: Model... - Page 21 Fig . 2 Fig . 3 B, C...
- Page 22 BDS Maschinen GmbH Martinstraße 108 D-41063 Mönchengladbach Fon: +49 (0) 2161 / 3546-0 Fax: +49 (0) 2161 / 3546-90 Internet: www.bds-maschinen.de E-mail: info@bds-maschinen.de...
