TECHNICAL INFORMATION

6.1 - Electrical Connections

L1
L2
U
W
V
X
W
Y
W
E
5
10
2
7
2
C1
1
2
10
11
ES
ES
STAGE 6
L1 L2 U V W X Y E
230V (a.c.) power input
Motor 1 single-phase 230V (a.c.) delayed opening
Motor 2 single-phase 230V (a.c.) delayed closure
230V (a.c.) output in motion (e.g. flashing light - max. 25W)
(24V-3W max.) "gate-opened" signal lamp
(N.O.) contact radio and/or button for control (see dip 2)
Contact (N.C.) for re-opening during the closing
Pushbutton stop (N.C.)
24V (a.c.) Powering accessories max. 20W
(12V-15W max.) connection for electrically-actuated lock
Antenna connection
5 C1 7 2 1 11 10
24
ES ES
