- Page 1 OPERATOR 119D U3 1 EN FOR SWING GATES INSTALLATION MANUAL F7024N English www.metalines.com sales@metalines.com...
-
Page 2: Read Carefully
• Cut other use is dangerous. CAME S.p.A. is not liable for any damage caused by off the power supply before releasing the operator for manual openings and improper, wrongful and unreasonable use •... -
Page 3: Legend Of Symbols
2 Intended use and limits to use 2.1 Intended use The F7024N gearmotor is engineered and built by CAME S.p.A. to comply with current safety laws and regulations, and to operate swing-gates in residential or apartment-block settings involving gate-leaves of no more than 300 kg. -
Page 4: Description Of Parts
4.3 Description of parts Gearmotor Post-fastening bracket Articulated arm Gate-fastening bracket Ddimensions Opening angle Hinge Closing strike plate. 140÷205 0÷50 140÷195 75÷100 90° 140÷185 125÷150 140÷175 175÷200 180÷210 110° 200÷205 = 240 mm max. with 90° opening www.metalines.com sales@metalines.com... -
Page 5: Installation
5 Installation Installation must be carried by skilled, qualified technicians in accordance with current regulations. 5.1 Preliminary checks Before beginning to install, do the following: • Set up a suitable omnipolar cut-off device, with distances greater than 3 mm between contacts, wit sectioned power source; •... -
Page 6: Standard Installation
Gearmotor 5.3 Standard installation Control panel Radiofrequency card Antenna Flashing light Selector Photocells Junction pit-box Mechanical stop plates 10. Transmitter 5.4 Tools and equipment Make sure you have all the tools and materials needed to carry out the installation in total safety and in accordance with current regulations. - Page 7 5.5 Applying brackets for fastening to the gate post, using fastening elements suitable for the materials and post - Fasten the base plate, using fastening elements suitable for the materials and post. - Fasten bracket A to gate the leaf according to the measurements in the table. 2.2 Limitations to useand the 68 mm distance between the two brackets, Gate "A"...
- Page 8 Fit the gearmotor into the post-mounted bracket; match the four holes and fasten it using the two issued M8x90 screws and M8 nuts (4). M8x90 5.7 Applying the articulated arm - Fit and fasten the straight arm in to the gearmotor shaft using a plug, bolt and accompanying distancer. Lubricate the bushing, fi...
- Page 9 5.8 Releasing the gearmotor To release the gearmotor, used the lever located above the rod. RELEASE LOCKING 5.9 Micro-switch settings See technical documentation of the ZL180 (319U17) control panel. www.metalines.com sales@metalines.com...
- Page 10 5.10 Electrical connections to the control panel Install the control panel and make the required electrical connections shown in the fi gure. ZL180 5.11 Cover mounting Once fi nished with mounting, electrical connections and adjustments, replace the cover and secure it using the hex M4 UNI5721 nut M4.
-
Page 11: Periodic Maintenance
7 Maintenance 7.1 Periodic maintenance The periodic maintenance actions to be done by the end users are: cleaning photocell glass; check proper working order of safety devices; remove any obstacles to the proper working order; We suggest to periodically check lubrication and tightness of fastening screws on the operator. To check efficiency of the safety devices, wave an object in front of the photocells during closing movement phase. -
Page 12: Troubleshooting
7.2 Troubleshooting MALFUNCTIONS POSSIBLE CAUSES CHECKS AND FIXES The gate neither • No power supply • Check if network is up opens nor closes • The gearmotor is released • Call for assistance • The transmitter battery is run down •... -
Page 13: Extraordinary Maintenance
7.4 Extraordinary maintenance The following table is for logging all extra-ordinary maintenance, repair and improvement jobs done by specialised contractors. N.B. All extraordinary maintenance jobs must be carried out by skilled technicians. Extraordinary maintenance log Installer’s stamp Operator name Date of job Technician’s segnature Requester’s segnature Job performed ________________________________________________________________________________________... -
Page 14: Dismantling And Disposal
On its premises, CAME S.p.A. implements a certified Environmental Management System in compliance with the UNI EN ISO 14001 standard to ensure environmental protection. Please help us to safeguard the environment. At CAME we believe this to be one of the fundamentals of ours market operations and development strategies. Just follow these short disposal instructions: DISPOSING OF THE PACKAGING The components of the packaging (i.e. -
Page 15: Compliance Statement
9 Compliance statement Declaration - CAME S.p.A. declares that this device complies with the essential requirements and other relevant provisions established in Directives 2006/42/CE e 2004/108/CE. Reference code for requesting a true copy: DDI B IT A001b www.metalines.com sales@metalines.com... - Page 16 HU • A vállalatra, termékeire és a műszaki szervizre vonatkozó minden további információért az Ön nyelvén: HR • Za sve dodatne informacije o poduzeću, proizvodima i tehničkoj podršci: UK • Для отримання будь-якої іншої інформації про компанію, продукцію та технічну підтримку: www. came.com www. came.com CAME S.p.A.
