Removal and Replacement Procedures

This section contains information about removal and replacement of all modules

in the instrument.

WARNING.

Before doing this or any other procedure in this manual, read the

safety summaries found at the beginning of this manual. Also, to prevent possible

injury to service personnel or damage to the instrument components, read

Installation in Section 2, and Preventing ESD in this section.

This subsection contains the following items:

This preparatory information that you need to properly do the procedures

that follow.

List of tools required to remove and disassemble all modules.

Procedures for removal and reinstallation of the modules.

WARNING.

Before doing any procedure in this subsection, disconnect the power

cord from the line voltage source. Failure to do so could cause serious injury

or death.

NOTE.

Read Equipment Required for a list of the tools needed to remove and

install modules in this instrument. (See Table 6 on page 23.) Read the cleaning

procedure before disassembling the instrument for cleaning.

Equipment Required. Most modules in the instrument can be removed with a

screwdriver handle mounted with a size T8 and T10 Torx screwdriver tips and a
