Tektronix WVR5200 Service Manual page 45

Fig. & index Tektronix part
number number
5-1
-1 174-5921-00
-2 211-1117-00
-3 214–4748–00
-4 863-6501-01
-5 129-1713-00
-6 863-6503-01
-7 211-0380-00
-8 863-6502-01
-9 146–0109–00
-10 214-5305-00
-11 260–5015–00
-12 348-2002-00
-13 200-5191-00
-14 211-0105-00
-15 333-4652-00
-16 214-3903-00
-17 210-1039-01
-18 220-0497-00
-19 878-6504-00
-20 441-2645-00
-21 119-7751-00
-22 211-0894-00
-23 174-5492-00
-24 863-6505-01
-25 260-2923-00
-26 333-4649-00
-27 366-0859-00
WVR5200 Waveform Rasterizer Service Manual
Qty Name & description
1 CABLE FPGA TO REF/IO 40 PIN
8 SCREW, MACHINE; 4-40 X 0.187, PAN HEAD, STEEL, ZINC FINISH, T-10, TORX DR
2 HEAT SINK, SEMIC; IC, PGA 11X11/MQUAD/27MM BGA;1.1 X 1.1 X 0.25 H, PIN FIN, AL, BLACK ANODIZE
1
CIRCUIT BOARD SUBASSY;FPGA
6 SPACER POST; .276 L, 4-40 M/F .188 HEX
1 CIRCUIT BOARD SUBASSY;SDI IO
2
SCREW, MACHINE; 4-40 X 0.375, FLH, STEEL, ZINC FINISH, T8
1 CIRCUIT BOARD SUBASSY;CPU
1 BATTERY, DRY; 3.0V, LITHIUM MANGANESE DIOXIDE, 210MAH, 20 X 3.22MM COIN CELL WITH SOLDER
TABS, CR2032-1HF1; SAFETY CONTROLLED
1 SPRING, GROUND CLIP FRONT PHONE JACK, USB
1 SWITCH, PUSH; SPST, TACT;50MA, 50V, MOMENTARY, SILVER CONTACTS;KSC221G, GULLWING SMD,
T & R
1 GASKET, EMI, 0.125 X 0.250 FOAM W/CONDUCTIVE FABRIC
1 TOP COVER CHASSIS
18 SCREW, MACHINE; 4-40 X 0.188, FLH, 100 DEG, ZINC PLATED STEEL, T8
1 PANEL, REAR WVR
4 VENDOR: LYNTRON...SCREW, JACK; 4-40 X 0.312 LONG, 0.188 H HEX HEAD STAND OFF, 4-40 INT THD, X
0.312 THD EXT 4-40, STEEL, ZINC PLATED
7 SCREW,MACHINE; M2.5 X 6MM,FLH,STL,CR PL,CROSS REC;3026
7 NUT, PLAIN, HEX; .5-28 X .562 HEX, BRS, NI (NICKEL) PLATED
1 CIRCUIT BOARD SUBASSY;REF IO,UNTESTED, 389441200 ROHS COMPLIANT
1 CHASSIS,MAIN (WVR)
2 FAN, DC: TUBEAXIAL, 12V, 5.6 CFM
4 SCREW, MACHINE; 4-40 X 0.625, PNH, STEEL, ZINC FINISH, T-10, TORX DR
1 CABLE ASSEMBLY, 10 PIN; FP TO MAIN; ROHS TO ROHS.
1 CIRCUIT BOARD SUBASSY;WVR FP
1 SWITCH KEYPAD (ELASTOMER MAT WVR)
1 FRONT PANEL ASSEMBLY, FRONT PANEL
1 ASSEMBLY, KNOB; .470 DIAMETER, SOFT TOUCH
Replaceable Parts
31
